1 : 8 Line Demultiplexer Manufacturer,Supplier and Exporter in India
Product Code : EL-DET-1524
Jlab Export is a leading 1 : 8 Line Demultiplexer Manufacturer,and suppliers in India
1 : 8 Line Demultiplexer (code EL-DET-1524) is a digital electronics training board for studying demultiplexing, in which one input is distributed to eight outputs under the control of three address inputs. SPDT switches set the logic levels, LEDs show the status, and a demultiplexer and timer are built into the panel. It is made by Jain Laboratory Instruments Pvt Ltd (JLab) at its works in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Experiment | Study of a 1 : 8 line demultiplexer |
| Signal path | One input demultiplexed to eight outputs |
| Control | Three control inputs (address) |
| Circuit blocks | Demultiplexer; timer |
| Switches | SPDT switches for logic selection |
| Indicators | LEDs for visual indication of status |
| Built-in power supply | +5 V DC at 50 mA, IC regulated, internally connected |
| Mains controls | Mains ON/OFF switch, fuse and jewel light |
| Supply required | 230 V ±10% at 50 Hz AC mains |
| Panel terminals | Terminals and sockets on the panel for connections and observation of waveforms |
| Operating instructions | Detailed instructions giving the object, theory, design procedures, report suggestions and book references |
| Other apparatus required | Dual-trace cathode ray oscilloscope, 20 MHz |
| Quality check | Each board is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-DET-1524 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
How Does It Compare with the JLab Digital Multiplexer?
| Board | Signal path | Control | Main circuit blocks | Other apparatus |
|---|---|---|---|---|
| 1 : 8 Line Demultiplexer (EL-DET-1524) | One input to eight outputs | Three control inputs (address) | Demultiplexer; timer; SPDT switches; status LEDs | Dual-trace cathode ray oscilloscope, 20 MHz |
| Digital Multiplexer | Eight inputs to one output | Three control signals | Multiplexer; SPDT switches; status LEDs | Requires no other apparatus |
Ordered together, the two boards show both ends of a multiplexed link: eight signals combined onto one line by the multiplexer, and one line shared out again to eight destinations by the demultiplexer.
What Is the 1 : 8 Line Demultiplexer Used For?
A demultiplexer is the reverse of a multiplexer. Its three address bits have eight combinations, and each combination connects the single input to one of the eight outputs while the others stay inactive. Demultiplexers separate signals that have been sent in turn over one channel, route data or clock pulses to one of several destinations, and act as decoders when the input is held at a fixed level. On this board students set the address with the SPDT switches, follow the status LEDs, and use a dual-trace oscilloscope to view the waveforms at the panel terminals, so they can see which output carries the input for every address — a clear demultiplexer experiment for a digital electronics course.
What to Specify When Ordering
- Board — this demultiplexer, the Digital Multiplexer, or both as a pair.
- Quantity — the number of boards for your digital electronics lab.
- Measuring instrument — a 20 MHz dual-trace cathode ray oscilloscope is needed as other apparatus; it is a separate instrument and can be quoted on the same enquiry.
Frequently Asked Questions
What does a 1 : 8 line demultiplexer do?
It takes one input line and passes it to whichever of its eight output lines is selected by the three-bit address. Changing the address moves the signal from one output to another.
How is a demultiplexer related to a decoder?
They are the same circuit used in two ways. With the data input held active, the address alone picks one output, which is decoding; with data applied to that input, the selected output follows the data, which is demultiplexing.
Why is a dual-trace oscilloscope needed?
The board calls for a 20 MHz dual-trace cathode ray oscilloscope as other apparatus. With two channels, the input waveform and a selected output can be displayed together and compared.
What power supply does the board use?
It runs from 230 V ±10% at 50 Hz AC mains, and the +5 V DC supply for its circuits is built in and IC regulated.
What information is needed for an export quotation?
Send the number of boards, the destination country and port or city, your preferred delivery terms (for example FOB or CIF), any packing or labelling requirements, and the tender reference if the order is for a tender.
Who manufactures the 1 : 8 Line Demultiplexer?
Jain Laboratory Instruments Pvt Ltd, trading as JLab, makes it at its works in Ambala, Haryana, India, and quotes for it directly.
OEM Manufacturer
JLab is the trading name of Jain Laboratory Instruments Pvt Ltd, a manufacturer of electronics training boards and laboratory equipment in India, incorporated in 2017 and based on Hargolal Road, Ambala, Haryana. The demultiplexer board is built at JLab’s own works rather than bought from a trader, so colleges, polytechnics, dealers and importers buy it factory-direct, each board is visually inspected before dispatch, and repeat orders and spares are handled by the manufacturer. The company is registered under CIN U29309HR2017PTC069123 and holds MSME Udyam registration UDYAM-HR-01-0003849 as a manufacturing enterprise. JLab exports worldwide and ships to buyers in every region — for example Tonga in Oceania, Sweden in Northern Europe, Barbados in Central America and the Caribbean, Argentina in South America and Togo in West Africa. Tender details are on the JLab lab tenders page.
Related Trainers and Instruments
- Digital Multiplexer — eight inputs selected onto one output by three control signals.
- 4 Line to 16 Line Decoder — a decoder/demultiplexer with sixteen outputs and four control signals, also used as a programmable sequencer.
- Dual Trace Oscilloscope — a 20 MHz dual-channel cathode ray oscilloscope, available as a separate instrument.
See the full Digital Electronics Trainer range or all Electronics Lab Equipments.
Request a Quote
Use the Add To Cart button to enquire about this board, or send the quantity, the delivery destination and whether an oscilloscope or the multiplexer board should be included through the contact page.
