CNC Milling Machine XL Manufacturer,Supplier and Exporter in India
Product Code : EL-CLE-9027
Jlab Export is a leading CNC Milling Machine XL Manufacturer,and suppliers in India
CNC Milling Machine XL (code EL-CLE-9027) is a CNC mill with a 700 x 180 mm working table, an 850 W motor and a 40 W coolant pump. It drills up to 20 mm, face mills up to 63 mm and end mills up to 20 mm, with a positioning accuracy of ±0.025 mm per 300 mm. Each XL mill is built by JLab in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Working table size | 700 x 180 mm |
| Max. drilling capacity | 20 mm |
| Max. face milling capacity | 63 mm |
| Max. end milling capacity | 20 mm |
| Positioning accuracy | ±0.025 mm / 300 mm |
| Motor power | 850 W, 230 V, 50 Hz |
| Coolant pump | 40 W |
| Quality check | Each XL milling machine is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 1 unit |
| Dispatch time | Usually 14–18 working days |
| Product code | EL-CLE-9027 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
What the Capacity Figures Mean
Drilling capacity is the maximum drill diameter the machine is rated to drive, and end milling capacity is the maximum end mill diameter, both 20 mm here. Face milling capacity, 63 mm, is the maximum face cutter diameter for machining flat surfaces. The positioning figure means a commanded move lands within 0.025 mm either side of its target over 300 mm of travel.
From CAD Drawing to G-code
The machine runs part programs in G-code. Simple profiles and hole patterns can be programmed by hand, while complex shapes are usually drawn in CAD and turned into tool paths and G-code by CAM software.
Other Mills and Milling Force Measurement
- CNC Milling Machine — production mill with three stepper-driven axes, ball screws and end mills.
- CNC Milling Trainer Deluxe — trainer with laser-engraved X-axis scales and electronic speed control.
- CNC Milling Machine Table Model — table model with a T-slotted worktable.
- Milling Tool — strain gauge octagonal rings for measuring milling forces in three directions.
It sits in CAD/CAM Lab Equipments under Mechanical Engineering Lab Equipment.
Request a Quote
Ask for an XL mill quotation through Add To Cart or the contact page, mentioning the quantity and the city and country of delivery.
