Condenser Fan Manufacturer,Supplier and Exporter in India
Product Code : EL-RACLE-12816
Jlab Export is a leading Condenser Fan Manufacturer,and suppliers in India
This condenser fan moves air over the condenser coil of a refrigerator or small cooling unit, carrying away the heat the refrigerant gives up. It is a 16 W fan for a 220-240 V, 50 Hz supply, fitted with an aluminium fan blade.
Specifications
| Power | 16 W |
| Supply | 220–240 V, 50 Hz |
| Fan blade | Aluminium |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 4–6 working days |
| Manufacturer | JLab (Jain Laboratory Instruments Pvt Ltd), Ambala, India |
Fan Fault-Finding for Students
A stopped condenser fan is a common fault on fan-cooled units: the compressor runs hot, the head pressure climbs and cooling falls off. On a training unit, students can stop the fan for a short time and watch the high-side reading rise on a set of Manifold Gauges For Refrigeration Systems.
To check the fan itself, they test the winding for continuity with a Digital Multimeter. They spin the blade by hand to feel for tight bearings and make sure the blade is firm on the shaft. After fitting, a Handheld Anemometer Digital held at the coil face shows whether air moves through the whole coil at an even speed.
Frequently Asked Questions
Which way should the condenser fan blow?
It should push air through the condenser coil in the direction the unit was built for. Fit the blade the same way round as the old one, and check the airflow over the coil once the unit is running.
What are the signs of a failed condenser fan?
The compressor and condenser get very hot, the compressor may trip on its overload, and the cabinet cools poorly. With gauges fitted, the high-side pressure reads well above its usual value.
Can a 16 W fan replace one of a different wattage?
Match the wattage, voltage, blade size and rotation of the old fan where you can. A lower-power fan may not move enough air over the coil, and a bigger one may not fit the mounting or the opening.
Why is the blade made of aluminium?
Aluminium is light, keeps its shape in the warm air near the condenser and does not rust. Keep the blade clean and straight, because a bent or dirty blade throws the fan out of balance.
Other Fans for Refrigeration Units
- Axial Flow Condenser Fans (aluminium body)
- Evaporator Fan
- Fan Cooled Condenser (PSC fan motor)
For a quote, use Add To Cart or send us a message through the contact page.
