Copper Pipe Cutter Manufacturer,Supplier and Exporter in India
Product Code : EL-RACLE-9364
Jlab Export is a leading Copper Pipe Cutter Manufacturer,and suppliers in India
This small tube cutter cuts soft copper pipe from 1/8 in to 3/8 in outside diameter, the sizes found on domestic refrigerators, small air conditioners and gauge lines. A hardened alloy steel wheel runs on a one-piece slide fed by a smooth-action thread. The die-cast body carries a deburring tool that folds away when not in use.
Specifications
| Tube size | 1/8 in to 3/8 in outside diameter |
| Body | Die-cast |
| Cutting wheel | Hardened alloy steel |
| Feed | Smooth-action thread, one-piece cutter slide |
| Deburring tool | Fold-away, carried in the body |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 4–6 working days |
| Manufacturer | JLab (Jain Laboratory Instruments Pvt Ltd), Ambala, India |
Workshop Practice with a Tube Cutter
In a refrigeration workshop, students cut short lengths from a roll of Copper Pipe in the 6 mm or 8 mm size. They set the wheel on the marked line, close it until it just grips, then turn the cutter round the pipe. The knob is tightened a little after every turn until the pipe parts.
The fold-away tool then scrapes the burr off the inside edge, and an Abrasive Strip (Sand Paper) cleans the outside before brazing. A cut end of 1/4 in or 3/8 in tube can go straight into a 45 Degree Flaring And Swaging Tool. Teachers can set a hacksaw cut beside a wheel cut to show why a square, clean end seals better under a flare nut.
Frequently Asked Questions
What tube sizes does this cutter handle?
It cuts tube from 1/8 in up to 3/8 in outside diameter, which covers the small soft copper lines on refrigerators and gauge lines. For bigger pipe, the heavy-duty Tube Cutter takes much larger copper and aluminium tube.
How do I stop the tube going oval or crushing?
Feed the wheel slowly. Close it until it just touches, make a full turn, then tighten the knob only slightly before the next turn. The groove deepens each time round. Forcing the wheel in at the start squeezes soft copper out of round.
Why remove the burr after cutting?
The wheel rolls a thin lip of copper into the bore. That lip narrows the opening, traps dirt and can stop a flare from seating. Turn the deburring tool inside the end with the tube pointing down, so the shavings fall out instead of into the pipe.
Why does the cutter spiral along the pipe instead of cutting a ring?
The wheel was usually closed too hard on the first turn, so it starts a thread instead of a groove. Dirt or flux in the rollers and worn pins can also tilt the wheel. Begin with a light scoring turn and keep the rollers clean and lightly oiled.
Other Copper Tube Tools
- Copper Pipe Bender
- Bending Spring
- Tube Cutter (mini cutter for copper)
- Reamer
