Frequency Shift Keying Modulation and Demodulation

Frequency Shift Keying Modulation and Demodulation

Product Code : JL-CT-1500

Frequency Shift Keying Modulation and Demodulation

Object:-
To study the generation of the Frequency Shift Keyed output and also to demodulate the FSK output.

Special Features:-
The board consists of the following built-in parts:-
± 12V D.C. at 20mA IC regulated power supply internally connected

5V D.C. at 100mA IC regulated power supply internally connected

Quad Op-amp IC

Decade counter IC

Timer IC

4-Bit Binary counter IC

Quad 2-input Nand gate IC

Two potentiometers for varying the FSK input and demodulator adjust

Adequate no. of other electronic components

Mains ON/OFF switch, fuse and jewel light

The unit is operative on 230V ±10% at 50Hz A.C. Mains

Adequate no. of patch cords stackable 4mm spring loaded plug length ½ metre

Good Quality, reliable terminal/sockets are provided at appropriate places on panel for connections /observation of waveforms

Strongly supported by detailed Operating Instructions, giving details of Object, Theory, Design procedures, Report Suggestions and Book References

Other Apparatus Required:-
Cathode Ray Oscilloscope 20MHz
