Function Generator 2 MHz

Function Generator 2 MHz

Product Code : JL-DSO-10297

Function Generator 2 MHz
Features:-
A low cost signal source for laboratory use
Output Waveform: Sine, Square, Triangle, Ramp, Pulse
Voltage Control Frequency (VCF) input
TTL output 50Hz Sine and single output
0.5Hz~30MHz(Ext.) Frequency Counter
Technical Specifications:-
Frequency range : 0.2Hz ~ 2MHz Digital (Model ME 920F)
Output waveform : Sine, Triangle, Square, Pulse, Ramp
Output impedance : 50ohms + 10%
Amplitude : >20Vp-p (1Mohm Load), >10Vp-p (50ohm Load)
DC offset : 0~+10V (1Mohm Load),  0~+5V (50ohm Load)
Symmetry range : 10% ~ 90%
Output attenuation : 20dB, 40dB, 60dB
Sine wave distortion : 20Hz ~ 20kHz<1 %
Frequency response : 2Hz ~ 2MHz < +1dB
Square wave rise or fall time : <30ns
TTL output : <50ns
Low level : <0.4V
High level : >3.5V
Impedance : 100ohm
VCF Input
Input voltage : -5V~0V
Input impedance : 10kohm +10%
50Hz Output : 2Vp-p, main synchrony
Frequency Counter:-
Display : 6 Digit
Measuring range : 0.5Hz ~ 30MHz
Input impedance : 10kohm +10%
Sensitivity : 200mV rms
Accuracy : 0.1Hz / 1Hz
Error : <0.1%+1digit
Max. Input voltage : 50Vp-p
Power requirement : 220 VAC +10% , 50 Hz
Weight : 3.0Kg Approx.
Dimensions (mm) : 250(L) x 275(B) x 100(H)
Standard Accessories:-
Power cable, BNC to Crocodile Clip Probes - 1No & BNC to BNC Probe - 1No.,
Instruction manual
