Rf Signal Generator 100Khz -150Mhz

Product Code : JL-DSO-10301

Rf Signal Generator 100Khz -150Mhz
A low cost signal source for laboratory use
Output Waveform: Sine and Amplitude modulation wave
RF/AM output, max, intensity > 10V p-p
External modulation signal can be set between 50Hz~20kHz
Technical Specifications:-
Frequency Range:-
A - 100kHz ~300kHz
B - 300kHz ~1MHz
C - 1MHz ~ 3.2MHz
D - 3MHz ~ 10MHz
E - 10MHz ~ 35MHz
F - 32MHz ~ 150MHz
Frequency range : 100kHz~150MHz
(3rd harmonic wave up to 450MHz)
Frequency accuracy : ±3%
Output waveform : RF/AM signal waveform
Output impedance : 600ohms
Radio frequency : Over 100mVrms (when frequency <35MHz)
Level control : 1mV~100mV
Internal modulation : 1kHz ± 2% >2Vrms output
External modulation : 50Hz ~ 20kHz for any setting
Power requirement : 220 VAC +10% , 50 Hz
Weight : 2.0Kg Approx.
Dimensions (mm) : 130(L) x 240(B) x 190(H)
Standard Accessories:-
Power cable, BNC to Crocodile Clip Probes - 1No & BNC to BNC Probe 1No.,
Instruction manual
