Digital Lab Trainer Manufacturer,Supplier and Exporter in India
Product Code : EL-DSO-10347
Jlab Export is a leading Digital Lab Trainer Manufacturer,and suppliers in India
Digital Lab Trainer (code EL-DSO-10347) is a digital electronics trainer kit on which students can perform more than 50 digital electronics experiments. Circuits are built on the breadboard provided on its glass epoxy front panel. It is made by Jain Laboratory Instruments Pvt Ltd (JLab) at its works in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Experiments | More than 50 digital electronics experiments |
| Front panel | Glass epoxy PCB, 300 mm x 220 mm, mounted on a lightweight shock-proof plastic cabinet |
| Breadboard | 2 vertically common strips (640 tie points each) and 4 horizontally common strips (100 tie points each) |
| Fixed DC supplies | +5 V / 1 A and −5 V / 500 mA, regulated |
| Variable DC supply | +3 V to +12 V / 500 mA, regulated |
| Load regulation | 0.2% |
| Line regulation | 0.05% |
| Ripple | Less than 3 mV RMS |
| Protection | Short-circuit and overload protected |
| Pulse generator | Square wave, 1 Hz to 1 MHz in 6 steps; amplitude 3 V to 15 V (CMOS) or 5 V (TTL); 50% duty cycle; TTL/CMOS output |
| Pulser switches | 2 push-to-on |
| Toggle switches | 8, for TTL and CMOS mode |
| LED display | 8 LEDs (TTL/CMOS mode) |
| Seven-segment displays | 3 |
| Logic probe | Logic level indicator for TTL/CMOS on a seven-segment display |
| Experiment modules | Compatible with optional ready-to-use experimental modules |
| Power requirement | 220 V AC +10%, 50 Hz |
| Weight | 3.0 kg approx. |
| Dimensions | 330 (L) x 225 (B) x 75 (H) mm |
| Standard accessories | 5 m hookup wire, 10 patch cords with a 2 mm banana plug on one end, power cord and instruction manual |
| Quality check | Each trainer is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-DSO-10347 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
How Does It Compare with Other JLab Digital Trainers?
| Trainer | Breadboard | Inputs and displays | Clock | DC supplies |
|---|---|---|---|---|
| This trainer (EL-DSO-10347) | 1680 tie points (2 x 640 + 4 x 100) | 8 toggle switches, 2 pulser switches, 8 LEDs, 3 seven-segment displays, logic probe | 1 Hz to 1 MHz square, 6 steps | +5 V / 1 A, −5 V / 500 mA, +3 to +12 V / 500 mA |
| Digital Logic Trainer | 1680 tie points (2 x 640 + 4 x 100) | 16 high/low switches, 16 LEDs, 4-digit seven-segment display with decoder driver | 1 Hz to 1 MHz, three ranges with multiplier | Fixed 5 V; variable 0 to ±18 V; 1 A |
| Digital Trainer Kit | 1880 tie points | 10 TTL/CMOS switches, 10 LEDs, four BCD seven-segment displays, logic pulser and logic probe | Fixed clock | +5 V and ±12 V |
All three are breadboard digital trainers. The Digital Logic Trainer has 16 input switches and 16 LEDs against 8 of each here, on the same 1680-point breadboard, while the Digital Trainer Kit offers the most tie points of the three, at 1880.
What Is the Digital Lab Trainer Used For?
It serves as the working bench for digital electronics practicals: students wire logic circuits on the breadboard, set inputs with the toggle and pulser switches, clock them from the pulse generator and read the results on the LEDs, seven-segment displays and logic probe. Typical practicals on such a trainer are logic gate truth tables, combinational circuits such as adders and multiplexers, flip-flops, counters and shift registers, in diploma, ITI and engineering electronics courses. Because the pulse output is 5 V in TTL mode and 3 V to 15 V in CMOS mode, the same trainer serves both the TTL and CMOS logic families.
What to Specify When Ordering
- Number of trainers for the digital electronics lab.
- Companion trainers, such as the Digital Logic Trainer or Microprocessor Trainer, which are separate items.
- Mains supply — the trainer is built for 220 V AC, 50 Hz.
Frequently Asked Questions
What power supplies are on the trainer?
Three regulated DC outputs: +5 V at 1 A, −5 V at 500 mA and a variable +3 V to +12 V at 500 mA. They are short-circuit and overload protected, with ripple below 3 mV RMS.
What comes with the trainer?
It is supplied with connecting wires: 5 m of hookup wire and 10 patch cords with a 2 mm banana plug on one end, together with a power cord and an instruction manual.
Are the experiment modules part of the trainer?
No — the ready-to-use experimental modules are optional. The trainer is compatible with them, and they are quoted as separate items.
What should an export quotation request contain?
The number of trainers, the destination country and port or city, your delivery terms (for example FOB or CIF), packing or labelling needs and any tender reference.
Who manufactures the Digital Lab Trainer?
JLab (Jain Laboratory Instruments Pvt Ltd) makes it at its works in Ambala, Haryana, and quotes for it directly as the manufacturer.
OEM Manufacturer
JLab is the trading name of Jain Laboratory Instruments Pvt Ltd, an electronics trainer and laboratory equipment manufacturer in India, incorporated in 2017 and based on Hargolal Road, Ambala, Haryana. The trainer is produced in JLab’s own works instead of being bought from a trader, so schools, colleges, ITIs, dealers and importers buy it from the maker, each unit is inspected visually before dispatch, and repeat orders come from the same factory. JLab exports worldwide and ships to buyers in every region — for example Uzbekistan in Central Asia, Taiwan in East Asia, Rwanda in East Africa, Tunisia in North Africa and Bolivia in South America. Tender information is on the JLab lab tenders page.
Related Digital and Microprocessor Trainers
- Digital Trainer — a breadboard trainer with 8 logic switches, 2 bounce-free pulse switches and a +5 V supply.
- Microprocessor Trainer — an 8-bit or 16-bit CPU trainer kit with an EPROM programmer interface.
- Stepper Motor Controller Trainer — stepper motor speed control by digital logic circuits or an 8-bit microprocessor.
More breadboard-based trainers are in the Breadboard Trainers range, within the Electronics Lab Equipments section.
Request a Quote
Ask for a quotation with the Add To Cart button or the contact page, giving the number of trainers and the delivery city and country.
