Hydraulic Flaring And Swaging Tool Kit Manufacturer,Supplier and Exporter in India
Product Code : EL-AELE-12906
Jlab Export is a leading Hydraulic Flaring And Swaging Tool Kit Manufacturer,and suppliers in India
A hydraulic pump does the forming in this kit, so flares and swages on the larger sizes take less effort than with a screw yoke. It flares and swages seven sizes from 1/4 in to 7/8 in. The 20-piece kit is packed in a moulded plastic box with its dies, swaging adapters, a 45° flaring cone, a reamer and a thread-cleaning brush.
Specifications
| Flaring sizes | 1/4, 5/16, 3/8, 1/2, 5/8, 3/4 and 7/8 in |
| Swaging sizes | 1/4, 5/16, 3/8, 1/2, 5/8, 3/4 and 7/8 in |
| Pieces | 20 |
| Kit contents | Flaring and swaging pump, yoke assembly, 45° flaring cone, 7 swaging adapters, 7-piece die set, inner-outer reamer, steel brush thread cleaner |
| Case | Plastic moulded box |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 4–6 working days |
| Manufacturer | JLab (Jain Laboratory Instruments Pvt Ltd), Ambala, India |
Practicals with the Hydraulic Kit
Air conditioning students use the larger sizes, up to 7/8 in, where a hand screw tool is hard work. They cut the tube, ream it with the kit reamer, set it in the matching die and pump the swaging adapter in to form a socket. The joint is brazed with Brazing Rod while dry nitrogen runs through it from the Nitrogen Flow Regulator Meter For Brazing.
Smaller sizes are flared with the 45° cone for flare nut joints. A useful comparison is the same flare made with the screw-type 45 Degree Flaring And Swaging Tool. The class can then judge the effort and the finish of each method.
Frequently Asked Questions
How does a hydraulic flaring and swaging tool work?
The tube is held in a die in the yoke. Working the pump builds oil pressure behind a ram, and the ram drives the flaring cone or a swaging adapter into the tube end. Releasing the pressure lets the ram return.
How do I know a flare is the right size?
Try the flare in its nut before fitting. The flared face should fill the cone seat of the nut out to its edge, with no overhang. A small flare seats on a narrow ring and leaks, and an oversized one binds in the nut.
What is the steel brush in the kit for?
It is a thread cleaner. Grit or old sealant in the threads of a flare nut or fitting stops it running up smoothly and can spoil the seal. The threads are brushed clean before assembly.
When is a hydraulic tool better than a screw-type one?
On the larger sizes and for repeated work. The pump does the forcing, so swaging 7/8 in tube takes little hand effort. A screw-type tool is smaller and simpler, and the 45 Degree tool also flares the small 1/8 and 3/16 in sizes.
