Eccentric Flaring Tool Manufacturer,Supplier and Exporter in India
Product Code : EL-AELE-12905
Jlab Export is a leading Eccentric Flaring Tool Manufacturer,and suppliers in India
An eccentric flaring tool forms the flare with an offset cone that rolls round inside the tube mouth, pressing the metal outward a little at a time. This kit flares tube of 1/4 in to 7/8 in OD in brass, aluminium, iron and other pipe used on automobiles and farm machinery. The tool is aluminium, and the kit adds an inner-outer reamer and a heavy-duty tube cutter for 4–28 mm.
Specifications
| Body | Aluminium |
| Pipe materials | Brass, aluminium, iron and other pipes |
| Flaring sizes | 1/4, 3/8, 1/2, 5/8, 3/4 and 7/8 in OD |
| Kit contents | Eccentric flaring tool, inner-outer reamer, heavy-duty tube cutter for 4–28 mm |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 4–6 working days |
| Manufacturer | JLab (Jain Laboratory Instruments Pvt Ltd), Ambala, India |
Workshop Practice with Eccentric Flaring
Everything for a first flared joint is in the kit. Students cut the tube with the kit cutter, ream the end and clamp it in the bar. The offset cone is then fed down slowly until the flare is formed, and backed off to show the finished face.
Automobile students can practise on brass and aluminium pipe as well as copper. Teachers can set a comparison with a flare made on the same size of tube by the 45 Degree Flaring And Swaging Tool. The two flared tubes are joined with a Union and tested under pressure with the Nitrogen Pressure Test Kit.
Frequently Asked Questions
What makes an eccentric flaring tool different?
Its cone is set off-centre and orbits as it is fed in, so it rolls the tube mouth outward instead of forcing it straight open. The wall is worked gradually, which gives a smooth flare face with less risk of splitting.
Which pipes and sizes can it flare?
Brass, aluminium, iron and other pipes on automobiles or farm machinery, in six sizes: 1/4, 3/8, 1/2, 5/8, 3/4 and 7/8 in OD.
Why does a flare joint leak after the nut is tightened?
Common causes are a flare too small to fill the nut, a scratch or burr on the flare face, and overtightening that crushes or cracks the flare. Check the face under good light, and cut it off and flare again if in doubt.
Can it swage tube ends for brazing?
No, it is a flaring tool only. For swaging use the Hydraulic Flaring And Swaging Tool Kit or the 45 Degree Flaring And Swaging Tool, as both have swaging adapters.
Other Tube Cutting and Forming Tools
- Tube Cutter (heavy-duty, for large tube)
- Reamer
- Tube Expander
For a quote, use Add To Cart or send us a message through the contact page.
