Lever with Supporting Stand for Torque and Equilibrium Investigations Manufacturer,Supplier and Exporter in India
Product Code : EL-CL-13436
Jlab Export is a leading Lever with Supporting Stand for Torque and Equilibrium Investigations Manufacturer,and suppliers in India
Lever with Supporting Stand for Torque and Equilibrium Investigations (code EL-CL-13436) is a 52 cm horizontal lever with a marked scale, mounted on a 42 cm vertical stand with a base, for studying torque, moments, balance, equilibrium, load and effort. Weights are set at measured distances along the scale and the beam is brought level. JLab builds this lever apparatus in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Model | JL/IPL-613 |
| Lever length | 52 cm |
| Stand height | 42 cm |
| Lever | Horizontal, with marked scale |
| Stand | Vertical, on a base |
| Frame | Metal |
| Quality check | Each lever and stand is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 4–6 working days |
| Product code | EL-CL-13436 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
The Principle of Moments on the Beam
The turning effect of a force about the pivot, its moment or torque, equals the force multiplied by the perpendicular distance from the pivot to the line of action of the force. The beam rests in equilibrium when the sum of the clockwise moments equals the sum of the anticlockwise moments. Hang a load on one side and an effort on the other, read both distances from the scale and compare force x distance on each side.
Load, Effort and Simple Machines
At balance, effort x effort distance = load x load distance, so an effort placed twice as far from the pivot as the load can balance a load twice its size. Moving the hanging weights along the scale shows how a lever trades force for distance, the working principle behind simple machines such as crowbars and see-saws.
Related Lever and Moment Apparatus
- Weights with Hooks — hooked masses for hanging loads and efforts on the beam.
- Lever Apparatus — a longer lever for first-, second- and third-class configurations.
- Moment of Force Apparatus — knife-edge clamps and mass hangers on a cast-iron support.
Further lever and moments apparatus is in the Chemistry Lab range.
Request a Quote
Request the lever and stand with Add To Cart or the contact page, stating how many sets you need and the delivery site.
