Portable Dissolved Oxygen Meter Manufacturer,Supplier and Exporter in India
Product Code : EL-ELA-5391
Jlab Export is a leading Portable Dissolved Oxygen Meter Manufacturer,and suppliers in India
Portable Dissolved Oxygen Meter (code EL-ELA-5391) is a battery-powered meter that measures dissolved oxygen (DO) from 0 to 20.0 ppm and temperature from 0 to 50 °C, with 0.1 ppm and 0.1 °C resolution. It uses an amperometric gold/silver membrane sensor, manual temperature compensation and a 3½-digit LCD, and is used for water-quality testing in environmental science teaching and field work. It is made by Jain Laboratory Instruments Pvt Ltd (JLab) at its works in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Range — dissolved oxygen | 0 to 20.0 ppm (mg/L) |
| Range — temperature | 0 to 50 °C |
| Resolution | DO 0.1 ppm; temperature 0.1 °C |
| Accuracy — dissolved oxygen | 0.1 ppm ± 1 count (as listed) |
| Temperature compensation | 0 °C to 50 °C, manual |
| Accuracy of compensation (DO) | ±3% |
| DO sensor | Amperometric, gold/silver membrane type |
| Display | 3½-digit seven-segment LCD |
| Power | 1 x 9 V battery |
| Quality check | Each meter is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-ELA-5391 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
How Does It Compare with Other JLab Dissolved Oxygen Instruments?
| Model | Display | Key listed features |
|---|---|---|
| This portable meter (EL-ELA-5391) | 3½-digit seven-segment LCD | DO 0 to 20.0 ppm and temperature 0 to 50 °C; gold/silver membrane sensor; manual temperature compensation; 9 V battery |
| Microprocessor Dissolved Oxygen Meter | 16x2 line alphanumeric LCD | DO and temperature measurement; 90-sample storage; printer attachment; auto/manual calibration; 8 soft-touch membrane keys |
| Dissolved Oxygen Test Kit | None (colour test) | Tablets for simple colour reaction tests, planned as a classroom water science lesson |
Choose the portable meter for battery-powered readings at a pond, tank or field site; the microprocessor meter suits a bench where stored results and printing matter, and the test kit lets a whole class run a colour test without an instrument.
What Is the Portable Dissolved Oxygen Meter Used For?
Dissolved oxygen is one of the main indicators of water quality: fish and other aquatic life need it, and low values point to organic pollution. The meter is used to check rivers, lakes, ponds and aquaculture tanks, to monitor aeration in effluent treatment, to take the initial and final DO readings in BOD tests, and in college and school environmental science practicals and projects. Because it runs on a 9 V battery, readings can be taken at the sampling point instead of carrying samples back to the lab, where their oxygen content can change.
In an amperometric membrane sensor, oxygen diffuses through the membrane to the electrodes and produces a current in proportion to the oxygen present, so the probe slowly consumes oxygen from the water next to it. Stir the sample or move the probe gently while reading, measure the water temperature and set it on the meter for the manual compensation, and keep the membrane clean and undamaged. Remove the battery if the meter will be stored for a long time.
What to Specify When Ordering
- Quantity — the minimum order is 10 meters; field courses often plan one per sampling team.
- Spares — ask for spare membranes and electrolyte in the same enquiry, as the listing does not state what is supplied with the probe.
- Companion instruments — add pH or other water-testing meters so a whole water-quality kit ships together.
Frequently Asked Questions
What is the measuring range of this DO meter?
Dissolved oxygen from 0 to 20.0 ppm (mg/L) with 0.1 ppm resolution, and temperature from 0 to 50 °C with 0.1 °C resolution.
What accuracy is listed?
The listing gives DO accuracy as 0.1 ppm ± 1 count and the accuracy of temperature compensation for DO as ±3%, with manual compensation from 0 °C to 50 °C.
What type of sensor does it use?
An amperometric gold/silver membrane sensor, which measures the current produced as oxygen passes through the membrane to the electrodes.
How is the meter powered?
By one 9 V battery, which makes it portable for field sampling. Readings are shown on a 3½-digit seven-segment LCD.
Is temperature compensation automatic?
No, it is manual. Measure the sample temperature and set it on the meter; compensation covers 0 °C to 50 °C.
What information is needed for an export quotation?
The quantity, destination country and port or city, preferred delivery terms such as FOB or CIF, any packing or labelling needs, and the tender reference if it is a tender purchase.
Who manufactures this meter?
Jain Laboratory Instruments Pvt Ltd, trading as JLab, makes it at its works in Ambala, Haryana, India, and quotes for it directly.
OEM Manufacturer
JLab is the trading name of Jain Laboratory Instruments Pvt Ltd, a manufacturer of laboratory instruments and science teaching equipment in India, incorporated in 2017 and based on Hargolal Road, Ambala, Haryana. This meter is produced at JLab’s own works rather than bought in from a trader, so colleges, schools, dealers and importers deal with the manufacturer directly, and repeat orders and spares are handled by the maker. JLab exports worldwide and ships to buyers in every region — for example Belgium in Western Europe, Guinea in West Africa, Vanuatu in Oceania, Bolivia in South America and Madagascar in East Africa. Tender information is on the JLab lab tenders page.
Water Testing Instruments
- Microprocessor Dissolved Oxygen Meter — a bench DO meter with sample storage and a printer attachment.
- Dissolved Oxygen Test Kit — a tablet-based colour test for classroom water science.
- pH-mv Temp. Meter — a digital instrument for pH, mV and temperature of liquids, to pair with DO readings.
Browse more in Educational Laboratory Apparatus or the full Laboratory Apparatus range.
Request a Quote
Quotes come direct from the manufacturer. Use the Add To Cart enquiry button on this page, or send the quantity (minimum 10 units), any spares or companion meters you need and your delivery location through the contact page.
