Punch & Chisel Set Manufacturer,Supplier and Exporter in India
Product Code : EL-CLE-9092
Jlab Export is a leading Punch & Chisel Set Manufacturer,and suppliers in India
Chisels and punches are struck with a hammer to cut, groove, mark and drive metal parts. This 12 piece set includes cold, cape and diamond point chisels with centre, solid, drift and pin punches. It comes in a wooden or metal holder.
Specifications
| Pieces | 12, in a wooden or metal holder |
| Cold chisels | 1/4 in and 5/8 in |
| Cape chisels | 1/4 in, and 5/16 in with round nose |
| Diamond point chisel | 3/8 in |
| Punches | Centre, solid and drift |
| Pin punches | 1/8 in and 5/32 in |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 4–6 working days |
| Manufacturer | JLab (Jain Laboratory Instruments Pvt Ltd), Ambala, India |
What Each Chisel and Punch Is For
The cold chisels cut and chip metal, for example shearing off a rivet head or cutting a bar on the anvil. A cape chisel has a narrow edge for keyways and slots. The round nose chisel cuts curved grooves and draws a drilled hole back to centre. The diamond point chisel cleans out corners and cuts V grooves.
The centre punch marks hole centres so the drill starts in the right place. The solid punch starts a tight pin or rivet moving. The drift punch lines up holes in two parts, and the pin punches drive a loosened pin right out.
Workshop Exercises with the Set
A common first-year fitting job is chipping a flat face on a mild steel block held in the Bench Vice, using the cold chisel and an Engineering Hammer. Later jobs add cutting a keyway with the cape chisel, then centre punching a marked-out plate before it is drilled on the Pillar Drill Machine.
Frequently Asked Questions
Which hammer should be used with these chisels?
Use an engineer’s ball pein hammer with a weight that suits the chisel. Hold the chisel loosely, watch the edge of the chisel rather than its head, and strike squarely.
In what order are the solid and pin punches used?
Start a tight pin with the solid punch, which has a tapered shank that takes heavy blows. Once the pin moves, change to the pin punch that fits and drive it out. A pin punch used first can bend.
What should be done when a chisel head mushrooms?
Grind the spread metal off the head and leave a small chamfer. A mushroomed head can throw off sharp chips when it is struck, so dress it before the chisel is used again.
How is a cold chisel sharpened?
Grind the edge on a bench grinder, keeping the two faces equal and dipping the chisel in water often so the tip does not lose its hardness. A slightly curved edge is normal for chipping.
Other Chisels, Punches and Stamps
- Flat Cold Chisel (chrome vanadium steel)
- Punches Set (twelve punches, rust protected)
- Punch Tool (centre punch)
- Figure Stamp Set (figures 0 to 9)
For a quote, use Add To Cart or send us a message through the contact page.
Last updated: 5 November 2026
