Universal Milling Machine Manufacturer,Supplier and Exporter in India
Product Code : EL-CLE-9033
Jlab Export is a leading Universal Milling Machine Manufacturer,and suppliers in India
Universal Milling Machine (code EL-CLE-9033) is a milling machine with a working table of at least 1200 x 280 mm with at least three T-slots about 14 mm wide, power and hand feed on all three axes and a motor of at least 3.7 kW. Spindle speeds run from 60 rpm or lower to 1400 rpm or higher. This universal mill comes from JLab, which makes it in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Working table | Min. 1200 x 280 mm or equivalent |
| T-slots | Min. 3, approx. 14 mm wide |
| Motor | Min. 3.7 kW, 380 V, 3 phase, 50 Hz |
| Longitudinal travel | Min. 880 mm, automatic and manual |
| Cross travel | Min. 250 mm, automatic and manual |
| Vertical travel | Min. 400 mm, automatic and manual |
| Spindle speed | From 60 rpm or less to 1400 rpm or more |
| Quality check | Each milling machine is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 1 unit |
| Dispatch time | Usually 14–18 working days |
| Product code | EL-CLE-9033 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
What Makes a Milling Machine Universal
On a universal milling machine the table can be swivelled in the horizontal plane, setting the work at an angle to the spindle for helical work as well as ordinary straight cuts. On this machine the table moves at least 880 mm lengthwise, 250 mm across and 400 mm vertically, each under power feed or by hand.
Clamping and Speeds
Work, vices and fixtures are bolted down through the T-slots in the table. The speed range, from no more than 60 rpm to no less than 1400 rpm, gives slow speeds for large cutters and tough material and higher speeds for small cutters.
Related Milling Machine, Arbors and CNC Retrofit Kit
- Universal Milling Machine — second model with angular table swivel and a 2 HP main motor.
- Long Milling Arbors — arbors for mounting cutters on horizontal and universal milling machines.
- CNC Retrofit Kit for Conventional Universal Milling Machine — kit for converting a conventional universal mill to CNC.
The machine appears in CAD/CAM Lab Equipments within Mechanical Engineering Lab Equipment.
Request a Quote
Get a quotation for the universal mill by using Add To Cart or the contact page and naming the quantity and the delivery site.
