Electrical Machine Trainer Manufacturer,Supplier and Exporter in India
Product Code : EL-FOT-10269
Jlab Export is a leading Electrical Machine Trainer Manufacturer,and suppliers in India
Electrical Machine Trainer (code EL-FOT-10269) is an electrical machines lab trainer whose control panels sit in a 40 x 40 mm aluminium profile rack with a sturdy table-top flat panel, built for starting, load and synchronising experiments on the machines supplied with it. It is made by Jain Laboratory Instruments Pvt Ltd (JLab) at its works in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Construction | Control panel in a 40 x 40 mm aluminium profile rack with sturdy table-top flat panel |
| Starter panel | 3-phase DOL starter, 4-pole MCB, contactor and relay panel |
| Meter panels | 3-phase multifunction meter panel (2 nos); instrumentation panel |
| Switch panel | FWD/REV, STAR/DELTA switch panel |
| Synchronising panels | Rotor and sync panel; synchronization panel |
| Supply panels | SCR-controlled variable DC panel (3 nos); variable AC/DC panel |
| Other panel | 1 ph. motor, voltmeter and ammeter panel |
| Load panels | 1-phase AC/DC resistive load panel; 3-phase resistive load panel; 3-phase inductive load panel; capacitive load panel |
| Machines supplied | 3-phase AC slip-ring star/delta induction motor; capacitor-start 1-phase induction motor; split-phase 1-phase induction motor; 3-phase synchronous motor; universal motor; 3-phase salient-pole alternator; DC machine motor/generator (trunnion); 3-phase 2-speed induction motor; DC machine motor |
| Quality check | Each trainer is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-FOT-10269 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
What Is the Electrical Machine Trainer Used For?
Electrical machines practicals look at how motors are started, reversed and loaded, how induction, synchronous, universal and DC machines differ, how an alternator is brought into synchronism, and how one DC machine can run as a motor or as a generator. This trainer brings that work onto one bench, with its panels and machines in a single set. Star/delta starting, for example, lowers the starting current of a three-phase induction motor compared with switching it straight on in delta, and swapping any two supply phases reverses its direction of rotation.
What to Specify When Ordering
- Number of trainer sets you need.
- Delivery destination — country and port or city, with your preferred delivery terms.
- Tender reference — if you are buying against a tender, send its number and specification so the quotation can follow it.
- Separate motors — any extra stand-alone motors from the JLab range, linked below, can be quoted on the same enquiry.
Frequently Asked Questions
Which machines are supplied with the trainer?
A 3-phase AC slip-ring star/delta induction motor, capacitor-start and split-phase 1-phase induction motors, a 3-phase synchronous motor, a universal motor, a 3-phase salient-pole alternator, a DC machine motor/generator on a trunnion, a 3-phase 2-speed induction motor and a DC machine motor.
What load panels does it have?
A 1-phase AC/DC resistive load panel, a 3-phase resistive load panel, a 3-phase inductive load panel and a capacitive load panel.
How are the motors started and reversed?
Through the 3-phase DOL starter, 4-pole MCB, contactor and relay panel, together with the FWD/REV and STAR/DELTA switch panel.
What variable supplies are provided?
Three SCR-controlled variable DC panels and a variable AC/DC panel.
What metering is on the trainer?
Two 3-phase multifunction meter panels, a voltmeter and ammeter panel, and an instrumentation panel.
How does it differ from the 3 Phase Induction Motor Trainer?
The 3 Phase Induction Motor Trainer is supplied with an induction motor and has an IGBT-controlled AC panel; this trainer is supplied with the single-phase, three-phase and DC machines named above, including a 3-phase salient-pole alternator.
What should an export enquiry for this trainer include?
The number of sets, the destination country and port or city, the delivery terms you want (for example FOB or CIF), any packing or labelling requirement and the tender reference if there is one.
Who manufactures the Electrical Machine Trainer?
Jain Laboratory Instruments Pvt Ltd, trading as JLab, builds it at its works in Ambala, Haryana, India, and quotes for it as the manufacturer.
OEM Manufacturer
JLab is the trading name of Jain Laboratory Instruments Pvt Ltd, an Indian manufacturer of engineering lab equipment and electrical and electronics trainers, incorporated in 2017 and based on Hargolal Road, Ambala, Haryana. The electrical machine trainer is built at JLab’s own works rather than bought from a trader, so colleges, institutes, dealers and importers buy it factory-direct, each set is visually inspected before it leaves the works, and repeat orders and spare parts are handled by the manufacturer. JLab exports worldwide and ships to buyers in every region — for example Canada in North America, Oman in the Middle East, Togo in West Africa, Malawi in East Africa and DR Congo in Central Africa. Institutions buying through tenders can find details on the JLab lab tenders page.
Related Motor Trainers and Machines
- 3 Phase Induction Motor Trainer — an induction motor trainer with an IGBT-controlled AC panel and a voltmeter and ammeter panel.
- Slip Ring Induction Motor — a separate slip-ring induction motor.
- Squirrel Cage Induction Motor — a separate squirrel cage induction motor with a cast iron frame.
Browse the Fiber Optic Trainers range or the full Electronics Lab Equipments range.
Request a Quote
Ask for a quotation with the Add To Cart enquiry button, or send the number of sets, any tender reference and the delivery location through the contact page.
