Flow Process Control Trainer Manufacturer,Supplier and Exporter in India
Product Code : EL-FOT-10251
Jlab Export is a leading Flow Process Control Trainer Manufacturer,and suppliers in India
Flow Process Control Trainer (code EL-FOT-10251) is a closed-loop trainer for studying PID control of flow. A flow measurement sensor feeds a digital indicating controller, and a pneumatic control valve, driven through an I to P converter, adjusts the flow. It is made by Jain Laboratory Instruments Pvt Ltd (JLab) at its works in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Type of control | PID |
| Control unit | Digital indicating controller, input 4–20 mA |
| Flow measurement sensor | Output 4–20 mA |
| I to P converter | Input 4–20 mA; output 3–15 psig |
| Control valve | Pneumatic; size 1/2 inch; input 3–15 psig; air to close; linear type |
| Rotameter | 10–200 LPH |
| Pump | Submersible, with sump tank |
| Air filter regulator | 0–2.5 kg/cm² |
| Pressure gauges | 0–2.5 kg/cm² and 0–7 kg/cm² |
| Power supply | 230 ± 10 V AC, 50 Hz, single phase, with on/off switch |
| Quality check | Each trainer is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-FOT-10251 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
How Does It Compare with Other JLab Process Control Trainers?
| Trainer | Controlled variable and sensor | Final control element | Other parts |
|---|---|---|---|
| This trainer (EL-FOT-10251) | Flow; flow measurement sensor | I to P converter and pneumatic control valve | Rotameter; submersible pump with sump tank |
| Pressure Process Control Trainer | Pressure; two-wire pressure transmitter | I/P converter and pneumatic control valve | MS process tank (pressure vessel) with output valve |
| Temperature Process Control Trainer | Temperature; RTD sensor | SSR proportional power controller and two-coil electric heater | Rotameter; insulated process tank |
All three use PID control with a digital indicating controller. Choose this trainer when the loop to be studied is flow rate; the pressure trainer applies the same control to the pressure in a vessel, and the temperature trainer to a heated, insulated tank.
What Is the Flow Process Control Trainer Used For?
It lets students work with and tune a complete control loop with industrial-style signals. The sensor’s current signal goes to the controller, which compares the measured flow with the set point and applies proportional, integral and derivative action; the I to P converter turns the controller’s current signal into an air-pressure signal that positions the valve. Changing the set point or the PID settings and watching the flow settle shows how each term affects the response.
What to Specify When Ordering
- The number of trainers, for example one per lab bench.
- Any other process control trainers, such as the pressure or temperature models, for the same lab.
- The tender reference, if the order is for a tender.
Frequently Asked Questions
What signals does the trainer use?
Standard 4–20 mA current signals at the flow sensor, the controller input and the I to P converter input, and a 3–15 psig pneumatic signal from the converter to the control valve.
What does “air to close” mean for the control valve?
Rising air pressure closes the valve, so if the air signal is lost the valve moves to its open position. With its linear characteristic, the flow through the valve changes roughly in proportion to its travel.
What power supply does it need?
230 ± 10 V AC, 50 Hz single-phase mains; the trainer has its own on/off switch.
Who manufactures this trainer?
Jain Laboratory Instruments Pvt Ltd (JLab) makes it at its Ambala works in Haryana, India.
OEM Manufacturer
JLab is the trading name of Jain Laboratory Instruments Pvt Ltd, an engineering lab equipment manufacturer in India, incorporated in 2017 and based on Hargolal Road, Ambala, Haryana. Each flow trainer is built at JLab’s own works, not bought from a trader, so colleges, institutes, dealers and importers order direct and repeat orders and spares go back to the maker. JLab exports worldwide and ships to buyers in every region — Gabon in Central Africa, Burkina Faso in West Africa, Eswatini in Southern Africa, Luxembourg in Western Europe and Brazil in South America, for example. Tender buyers can refer to the JLab lab tenders page.
Related Flow and Valve Trainers
- Control Valve Characteristics Trainer — three pneumatic control valves, linear, equal-percentage and quick-opening, for comparing valve characteristics.
- Rotameter Test Rig — a pump-circulated rig with a rotameter, sump tank and measuring tank.
This trainer is listed in the Fiber Optic Trainers section of Electronics Lab Equipments, alongside JLab’s other trainers.
Request a Quote
For a quotation, press the Add To Cart enquiry button or use the contact page, with the number of trainers, any other process control trainers to include, the delivery destination and your preferred delivery terms such as FOB or CIF.
