FPGA Development Board Manufacturer,Supplier and Exporter in India
Product Code : EL-PET-10191
Jlab Export is a leading FPGA Development Board Manufacturer,and suppliers in India
FPGA Development Board (code EL-PET-10191) is a field-programmable gate array (FPGA) trainer for digital design practice, produced in Ambala, India, by Jain Laboratory Instruments Pvt Ltd (JLab). Its clock generator gives six frequencies from 20 MHz down to 1 Hz, so a design can be watched step by step at the slowest setting or run at the higher frequencies.
Specifications
| Parameter | Detail |
|---|---|
| Programming | On-board ISP programmer for piggyback modules |
| Inputs | 8 toggle input switches; 16 DIP switches |
| Outputs | 16 outputs with LED indication |
| Displays | 6-digit seven-segment display; 16x1 LCD |
| Keyboard | 4x4 matrix keyboard |
| Analog interface | 8-bit ADC; 8-bit DAC |
| Other on-board devices | Relay; matrix LED; stepper motor; LM35 |
| Clock generator | 20 MHz, 10 MHz, 1 MHz, 100 kHz, 1 kHz and 1 Hz |
| Built-in power supply | +5 V / 1.5 A; ±12 V / 250 mA |
| Quality check | Each board is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-PET-10191 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
What Is the FPGA Development Board Used For?
An FPGA is a chip whose internal logic is configured by the user, so one device can become a counter, a decoder or a complete digital controller. Designs can be tested on the board’s switches, keypad, LEDs, displays, stepper motor and relay, with the ADC and DAC linking them to analog signals.
Frequently Asked Questions
How is an FPGA board different from a microcontroller board?
A microcontroller runs a stored program instruction by instruction; an FPGA is configured into hardware logic that can perform many operations in parallel. For microcontroller work JLab offers the Microcontroller Board (LED Variant), which also has a six-digit seven-segment display and the same +5 V / 1.5 A and ±12 V / 250 mA supply ratings.
What does the on-board ISP programmer do?
It programs the piggyback modules in-system, while they stay on the board, so a design can be changed and reloaded between tests.
Who manufactures this FPGA board?
Jain Laboratory Instruments Pvt Ltd, trading as JLab, at its works in Ambala, Haryana.
OEM Manufacturer
JLab is the trading name of Jain Laboratory Instruments Pvt Ltd, a maker of electronics trainers and engineering lab equipment in India, incorporated in 2017 and based on Hargolal Road, Ambala, Haryana. Boards come from its own works, not a trader, and go direct to schools, colleges, dealers and importers, with repeat orders and spares from the same source. JLab ships worldwide to every region — Myanmar in Southeast Asia, Nepal in South Asia, Malawi in East Africa, North Macedonia in Southern Europe and Brazil in South America, for example. Tender enquiries: JLab lab tenders page.
Related Boards and Trainers
- Embedded Board — a microcontroller board with ISP programming, an LCD, ADC, DAC and a temperature sensor.
- Advance Digital Electronics Trainer — an on-board CPLD for programmable logic beside a 1280 tie-point breadboard.
- DSP Development Board — USB-based programming, a codec, SDRAM and flash ROM.
See also Power Electronics Trainers and Electronics Lab Equipments.
Request a Quote
Use Add To Cart on this page or the contact page, with the quantity, the destination country and city, and any tender reference.
