Hydraulic Bench Manufacturer,Supplier and Exporter in India
Product Code : EL-HM-7403
Jlab Export is a leading Hydraulic Bench Manufacturer,and suppliers in India
Hydraulic Bench (code EL-HM-7403) is a self-contained, water re-circulating bench with a top tray and a sump tank, on which various hydraulics experiments are run and their flow rate measured with a measuring tank and stopwatch. An FHP centrifugal pump circulates the water, and a flow control valve and by-pass valve in the water line set different flow rates. The bench is manufactured in Ambala, India, by JLab.
Specifications
| Parameter | Detail |
|---|---|
| Type | Self-contained, water re-circulating |
| Tanks | Top tray and sump tank |
| Pump | FHP (fractional horsepower) centrifugal pump |
| Flow adjustment | Flow control valve and by-pass valve in the water line |
| Flow measurement | Measuring tank and stopwatch |
| Quality check | Each hydraulic bench is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 1 unit |
| Dispatch time | Usually 14–18 working days |
| Product code | EL-HM-7403 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
Measuring Flow Rate on the Bench
Water leaving the experimental set-up drains onto the top tray and returns to the sump tank, so the same water circulates throughout a session. To find the flow rate, the outflow is collected in the measuring tank over a timed interval: discharge Q equals the volume collected divided by the time taken. Repeating the reading at several valve settings covers the range of flows an experiment needs.
Setting the Flow with Two Valves
The flow control valve throttles the supply to the experiment, while the by-pass valve returns part of the delivery of the pump to the sump. Opening the by-pass lowers the flow reaching the experiment without working the pump against an almost closed valve, which helps when low flow rates are wanted.
Related Benches, Flow Meters and Timers
- Hydraulics Bench — portable, self-contained service module for fluid mechanics accessories.
- Venturimeter and Orificemeter Calibration Set-Up — venturimeter and orifice meter in parallel pipelines with a differential manometer.
- Digital Stopwatch — timer reading to hundredths of a second, with alarm.
It appears in Hydraulic Machine under Fluid Mechanics and Hydraulics Lab Equipment.
Request a Quote
To get a quote, press Add To Cart or message us from the contact page with the number of benches and the delivery town.
