Joints, Spherical, Female Manufacturer,Supplier and Exporter in India
Product Code : EL-SDAJ-1669
Jlab Export is a leading Joints, Spherical, Female Manufacturer,and suppliers in India
Joints, Spherical, Female (code EL-SDAJ-1669) are the cup halves of glass ball-and-socket joints, each on a 100 mm shank, in sizes S13 to S51 plus an S13 with a capillary bore. The shank is fused onto tubing or apparatus so the cup can take a male ball of the same size. JLab makes these sockets in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Joint type | Spherical, female (socket) |
| Socket sizes | S13 capillary bore, S13, S19, S29, S35, S41, S51 |
| Shank length | 100 mm |
| Quality check | Each socket joint is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 50 units |
| Dispatch time | Usually 3–5 working days |
| Product code | EL-SDAJ-1669 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
Why a Ball-and-Socket Joint Moves
The cup and the ball are both parts of a sphere, so the two halves can meet at a slight angle rather than exactly in line, giving some angular movement within a glass set-up. The joint does not lock by itself; a pinch clamp is normally used to hold the pair together. The S number roughly equals the ball diameter in millimetres.
Matching and Alternative Joints
- Joints, Spherical, Male — ball halves made in the same S13 to S51 sizes.
- Joints, Socket, Single — tapered sockets in B sizes for cone-and-socket joints.
- Joints, Flat Flange — flange joints with bores from 10 to 100 mm.
Browse every joint and disc in Screwthreads, Discs and Joints under Lab Glassware.
Request a Quote
Add the sockets with Add To Cart, noting the S size and quantity of each, or write through our contact page with your delivery city.
Last updated: 29 October 2026
