Magnetic Compass Manufacturer,Supplier and Exporter in India
Product Code : EL-PL-13407
Jlab Export is a leading Magnetic Compass Manufacturer,and suppliers in India
Magnetic Compass (code EL-PL-13407) is a 50 mm compass whose magnetic needle sits in a metal case under a hinged glass cover, over a dial marked with the principal points in large lettering. A locking mechanism holds the needle still while the compass is carried. JLab makes this compass in Ambala, India, for physics and geography classes.
Specifications
| Parameter | Detail |
|---|---|
| Model | JL302 |
| Diameter | 50 mm |
| Case | Metal, with hinged glass cover |
| Dial | Marked with the principal points of the compass |
| Needle | Magnetic, with a locking mechanism |
| Dial lettering | Large font |
| Quality check | Each compass is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 4–6 working days |
| Product code | EL-PL-13407 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
Taking a Bearing
Release the lock, hold the compass level and keep it clear of steel benches, magnets and current-carrying wires. When the needle settles, turn the case until the N on the dial sits under the north-seeking end; every other direction can then be read straight off the dial. Lock the needle again before closing the lid, so the pivot is not knocked about in a bag.
Magnetic North and Magnetic Fields
The needle lines up with the Earth’s magnetic field, so it points to magnetic north, which differs from true north by the local declination. Placed beside a bar magnet, the same needle shows the direction of the magnet’s field at that spot, and its north-seeking end turns towards the magnet’s south pole.
Related Magnetism Apparatus
- Magnetic Compass Small Size — a smaller dial-less compass with the needle between two glass plates.
- Magnetic Needle — a carbon steel needle on a brass cup bearing, with a plastic stand.
- Bar Magnet — a red-and-blue bar magnet for checking the field direction with the compass.
- Deflection Magnetometer — a removable compass box on a wooden base with a metre scale.
More magnetism and electricity apparatus sits in the Physics Lab category.
Request a Quote
Add the compasses you need with Add To Cart, or send the quantity and delivery address through the contact page, and JLab will reply with a quotation.
