Model of Cochran Boiler Manufacturer,Supplier and Exporter in India
Product Code : EL-AM-6080
Jlab Export is a leading Model of Cochran Boiler Manufacturer,and suppliers in India
Model of Cochran Boiler (code EL-AM-6080) is a teaching model of the Cochran boiler, a well-known vertical fire-tube boiler, with a shell about 25 cm in diameter and 60 cm high. It shows how hot gases travel from the fire box through the tubes to the chimney. It is made by Jain Laboratory Instruments Pvt Ltd (JLab) at its works in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Boiler type | Vertical fire-tube boiler, Cochran type |
| Shell | About 25 cm in diameter and 60 cm high |
| Fire box | Cylindrical, with a door and a grate at its bottom |
| Gas path | Hot gases pass from the fuel to the combustion chamber through a short flue pipe, then through the tubes to the chimney |
| Tubes | Covers at both ends; the tubes can be cleaned once the covers are removed |
| Mountings | Feed check valve, steam gauge, water gauge, stop valve, safety valve and manhole |
| Quality check | Each model is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-AM-6080 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
What Is the Cochran Boiler Model Used For?
It is used to teach steam boilers in mechanical and thermal engineering, for example in ITI, polytechnic and engineering college labs. In a fire-tube boiler the hot gases flow inside the tubes and the water surrounds them, the reverse of a water-tube boiler. A vertical design such as the Cochran needs little floor space, which suited plants that needed only a modest supply of steam.
Frequently Asked Questions
What do the mountings on the model do?
The safety valve releases steam if the pressure rises above its set limit; the feed check valve lets feed water into the boiler but stops it flowing back; the stop valve controls the steam leaving the boiler; the water gauge shows the water level and the steam gauge the pressure; and the manhole gives access for inspection and cleaning.
Why do the tubes have covers at both ends?
Soot and ash from the hot gases collect inside fire tubes and reduce heat transfer, so the covers can be taken off and the tubes cleaned.
What should an export enquiry include?
The quantity, the destination country and port or city, delivery terms such as FOB or CIF, packing or labelling needs and any tender reference.
OEM Manufacturer
JLab is the trading name of Jain Laboratory Instruments Pvt Ltd, an Indian manufacturer of engineering lab equipment and teaching models, incorporated in 2017 and based on Hargolal Road, Ambala, Haryana. The Cochran boiler model is built in JLab’s own works rather than bought from a trader, and institutes, dealers and importers order it direct from the manufacturer. JLab is registered for GST under GSTIN 06AADCJ9848D1ZE and holds Legal Entity Identifier 549300DTGS77DGYD6N03. JLab exports worldwide and ships to buyers in every region — for example the UAE in the Middle East, Taiwan in East Asia, Hungary in Eastern Europe, Turkmenistan in Central Asia and Angola in Central Africa. For institutional purchases see the JLab lab tenders page.
Other Boiler Models
- Model of Lancashire Boiler — two large fire tubes running from end to end, with the model made dissectible for demonstration.
- Model of Locomotive Boiler — fire tubes leading to a smoke box with nozzle and blast pipe, and a dissected barrel.
- Model of Babcock and Wilcox Boiler — a water tube boiler with a superheater and inclined water tubes over the furnace.
- Vertical Water Tube Boiler — a cylindrical fire box fitted with cross tubes.
- Model of Marcet Boiler — a stove-heated working model with a pressure gauge and thermometer jacket.
The boiler models are listed in the Anatomical Models range and its sub-category.
Request a Quote
To receive a quotation, use the Add To Cart enquiry button or the contact page, and list the boiler models and quantities you need with the delivery destination.
