Single Stage Air Compressor Test Rig Manufacturer,Supplier and Exporter in India
Product Code : EL-TL-10056
Jlab Export is a leading Single Stage Air Compressor Test Rig Manufacturer,and suppliers in India
Single Stage Air Compressor Test Rig (code EL-TL-10056) is a bench built around a single-cylinder, single-stage air compressor driven by a 2 hp three-phase motor, both mounted on the air receiver. An orifice with a water manometer measures the air drawn in and an energy meter the power input, so students can find volumetric and isothermal efficiency at various discharge pressures. JLab manufactures this compressor test rig in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Compressor | Single cylinder, single stage |
| Drive | 2 hp three-phase motor |
| Mounting | Compressor and motor on the air receiver, with delivery valve |
| Controls | Air relief valve and pressure switch |
| Air intake measurement | Air tank and orifice with water manometer |
| Instruments | Discharge pressure gauge; digital temperature indicator; energy meter for input power |
| Services required | 440 V, 15 A, three-phase AC with neutral and earthing; hand tachometer; floor space 2.5 m x 1.5 m |
| Documentation | Technical manual |
| Quality check | Each compressor test rig is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 1 unit |
| Dispatch time | Usually 14–18 working days |
| Product code | EL-TL-10056 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
Measuring the Air Drawn In
The compressor takes its air from the air tank, which in turn fills through the orifice. A piston compressor draws in pulses, and the tank smooths them so the orifice sees a steady flow. The water manometer reading h across the orifice is converted to a head of air, H = h ρw/ρa, and the free air delivered at intake conditions is Va = Cd A √(2gH), with A the orifice area and Cd its discharge coefficient. The digital temperature indicator gives the air temperatures needed for the air density.
Volumetric and Isothermal Efficiency
The hand tachometer gives the speed N, and the swept volume per second follows from the bore, stroke and N. Volumetric efficiency is Va divided by the swept volume; it falls as discharge pressure rises, because the air left in the clearance space re-expands before fresh air can enter. Isothermal power is p1 Va ln(p2/p1), with absolute intake and delivery pressures, and dividing it by the input power from the energy meter gives the isothermal efficiency. Each delivery pressure is set with the delivery valve and held steady while readings are taken; the rise in air temperature through the compressor shows how far the real process is from isothermal.
