Study of Encoder and Decoder Circuits Decimal to BCD Encoder and BCD to 7-segment Decoder Manufacturer,Supplier and Exporter in India
Product Code : EL-DEECP-1179
Jlab Export is a leading Study of Encoder and Decoder Circuits Decimal to BCD Encoder and BCD to 7-segment Decoder Manufacturer,and suppliers in India
Study of Encoder and Decoder Circuits Decimal to BCD Encoder and BCD to 7-segment Decoder (code EL-DEECP-1179) is a digital electronics trainer for studying decimal to BCD encoding and BCD to 7-segment decoding. Its printed circuit diagram covers the IC 7490, the IC 7447 and a 7-segment display, with a DC power supply, a 1 Hz clock pulse, four SPDT logic switches and four output indicators, for college, polytechnic and ITI labs. It is made by Jain Laboratory Instruments Pvt Ltd (JLab) at its works in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Experiments | Decimal to BCD encoder and BCD to 7-segment decoder |
| ICs and display in the circuit diagram | IC 7490, IC 7447 and 7-segment display |
| Power supply | DC power supply, built in (rating not stated in this listing) |
| Logic switches | 4 SPDT switches for selecting logic 1 and logic 0 |
| Clock | 1 Hz clock pulse |
| Output indicators | Four |
| Circuit diagram | Printed on the trainer |
| Connections | Inputs and outputs brought out to sockets on the front panel |
| Quality check | Each trainer is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-DEECP-1179 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
How Do the Encoder and Decoder Circuits Work?
Binary-coded decimal (BCD) represents each decimal digit with four bits, so an encoder turns a decimal value into those four bits and a decoder turns them back into something people can read. The two ICs on this trainer cover both sides. The IC 7490 is a decade counter: it counts clock pulses through ten states and presents each count as a BCD code, which the four output indicators can show bit by bit. The IC 7447 is a BCD to 7-segment decoder/driver whose active-low outputs switch the segments of a common-anode display, lighting the right pattern of the seven segments for each digit.
With the slow 1 Hz clock, students can follow the BCD code on the four indicators and relate it to the segment pattern the IC 7447 produces for each digit, then use the SPDT switches to apply logic levels and the front-panel sockets to trace each connection. The same chain of counter, decoder and display is found in digital clocks, event counters and panel meters, which makes this a practical experiment for B.Sc. physics and electronics, engineering diploma and ITI digital electronics courses. The listing does not name a separate decimal to BCD encoder IC, so confirm the encoder section with JLab if your practical manual specifies one.
What to Specify When Ordering
- Encoder section — confirm the encoder arrangement if your syllabus names a particular encoder IC.
- Mains supply — state your supply voltage, as the power-supply rating is not listed.
- Quantity — the minimum order is 10 units.
Frequently Asked Questions
Which ICs are shown on this trainer?
The printed circuit diagram covers the IC 7490 decade counter, the IC 7447 BCD to 7-segment decoder and a 7-segment display.
What does the IC 7447 do?
It converts a 4-bit BCD input into the seven segment signals needed to show that digit on a common-anode 7-segment display.
What clock and indicators does it have?
A 1 Hz clock pulse and four output indicators, together with four SPDT switches for setting logic 1 or logic 0.
How does it differ from the BCD to decimal decoder trainer?
That trainer decodes BCD to ten separate LED outputs, one per digit. This one decodes BCD to the segments of a 7-segment display and adds a decade counter and clock.
Who manufactures this trainer?
Jain Laboratory Instruments Pvt Ltd, trading as JLab, at its works in Ambala, Haryana, India.
OEM Manufacturer
JLab is the trading name of Jain Laboratory Instruments Pvt Ltd, a manufacturer of digital electronics trainers and laboratory equipment in India, incorporated in 2017 and based on Hargolal Road, Ambala, Haryana. This encoder and decoder trainer is made at JLab’s own works, not bought in from a trader, so colleges, dealers and importers get it factory-direct, every unit is visually inspected before dispatch, and repeat orders come from the same manufacturer. JLab exports worldwide and ships to buyers in every region — for example the UAE in the Middle East, Hungary in Eastern Europe, Kyrgyzstan in Central Asia, Sudan in North Africa and Canada in North America.
Related Code Conversion Trainers
- BCD to Decimal Decoder Trainer — BCD decoded to ten separate LEDs.
- Decimal to Binary Encoder Trainer using NAND Gates — an encoder built from gates, with ten decimal inputs.
- 4 Bit Up and Down Counter Trainer — another counter IC with a 1 Hz clock and four outputs.
See the full Digital Electronic Experiments Computer Principles range or all Scientific Instrument products.
Request a Quote
Quotes come direct from the manufacturer. Use the Add To Cart enquiry button on this page, or send the quantity (minimum 10 units), your mains supply and your delivery location through the contact page.
