Two Cylinder Four Stroke Diesel Engine Test Rig Manufacturer,Supplier and Exporter in India
Product Code : EL-TELE-9434
Jlab Export is a leading Two Cylinder Four Stroke Diesel Engine Test Rig Manufacturer,and suppliers in India
This test rig runs a two cylinder, four stroke diesel engine and measures the heat its water jacket rejects as well as its power and fuel use. The engine sits on a welded steel base plate with anti-vibration mounting and a guarded drive shaft. It can be loaded by an AC alternator, a mechanical brake, a hydraulic dynamometer or an eddy current dynamometer.
Specifications
| Engine | Two cylinder, four stroke, diesel (compression ignition) |
| Base | Welded steel base plate, anti-vibration mounting |
| Drive | Drive shaft with safety guard |
| Loading options | AC alternator, mechanical brake, hydraulic dynamometer or eddy current dynamometer |
| Resistance loading | Resistance bank with selector switches, no load to full load (where applicable) |
| Panel board | Fuel system with burette flow measurement, air flow measurement system, temperature and speed indicator |
| Experiments | Brake power, brake thermal efficiency, fuel consumption, air intake, heat rejected to water jacket |
| Minimum order quantity | 1 unit |
| Dispatch time | Usually 14–18 working days |
| Manufacturer | JLab (Jain Laboratory Instruments Pvt Ltd), Ambala, India |
Performance and Jacket Heat Practicals
A typical practical holds the engine at constant speed and raises the load from no load to full load in steps. At each step students record brake load, speed, burette fuel time and air flow. They also note the jacket water flow and its inlet and outlet temperatures.
Multiplying the jacket water mass flow by its specific heat and its temperature rise gives the heat carried off by the jacket. Set beside brake power and the heat supplied by the fuel, it shows where the energy goes as load rises. The fuel calorific value comes from a Digital Bomb Calorimeter, and a Diesel Engine Compression Tester checks both cylinders before the test series.
Frequently Asked Questions
How does the hydraulic dynamometer option work?
It absorbs engine power by churning water inside a casing. The casing tends to turn with the rotor, and the force that holds it at a known arm gives the torque. The load is changed by the amount of water in the casing.
Why measure the heat rejected to the water jacket?
The cooling water carries off a large share of the fuel energy, often second only to the exhaust. Measuring it shows students how much energy the cooling system removes and is the first step toward a full heat balance.
Does the load change in steps?
With the AC alternator, yes. The resistance bank is switched in with selector switches, so load rises in steps from no load to full load. The mechanical brake, hydraulic and eddy current options can be set between those steps.
How does it compare with the single cylinder diesel rig?
The Single Cylinder Four Stroke Diesel Engine Test Rig runs on a rope brake and covers power, efficiency, fuel and air tests. This two cylinder rig offers four loading units and adds the heat rejected to the water jacket.
Other Engine Test Rigs and Tools
- Multi Cylinder Four Stroke Petrol Engine Test Rig
- Variable Compression Ratio Engine Test Rig
- Diesel Injector Tester
- Gas Exhaust Analyzer
For a quote, use Add To Cart or send us a message through the contact page.
