Condensers Air Manufacturer,Supplier and Exporter in India
Product Code : EL-C-1596
Jlab Export is a leading Condensers Air Manufacturer,and suppliers in India
Condensers Air (code EL-C-1596) are air condensers: a glass tube with a ground-glass socket and cone and no water jacket, cooled only by the air around it. Seven sizes run from a 100 mm effective length with B10 joints to 550 mm with B24 or B29 joints. JLab produces this condenser range in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Type | Air condenser, no water jacket |
| B10 socket / B10 cone | Effective length 100 mm, overall 120 mm, surface area 30 cm² |
| B14 socket / B14 cone | Effective length 200 mm, overall 225 mm, surface area 100 cm² |
| B19 socket / B19 cone | Effective length 150 mm, overall 170 mm, surface area 100 cm² |
| B19 socket / B19 cone | Effective length 300 mm, overall 320 mm, surface area 200 cm² |
| B19 socket / B24 cone | Effective length 400 mm, overall 430 mm, surface area 400 cm² |
| B24 socket / B24 cone | Effective length 550 mm, overall 570 mm, surface area 400 cm² |
| B29 socket / B29 cone | Effective length 550 mm, overall 570 mm, surface area 500 cm² |
| Quality check | Each condenser is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 50 units |
| Dispatch time | Usually 3–5 working days |
| Product code | EL-C-1596 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
When Air Cooling Is Enough
With no jacket and no hoses, the vapour gives up its heat through the glass wall to the room. That suits liquids with a high boiling point, which condense readily on a cool surface; a low-boiling solvent would escape and needs a water-cooled condenser such as the Liebig.
Choosing a Size
Cooling capacity follows surface area, from 30 cm² on the shortest tube to 500 cm² on the B29 model. The model with a B19 socket and a B24 cone joins a B24 flask neck to B19 glassware above it.
Related Condensers and Fittings
- Condensers, Liebig — straight water-jacketed condenser for lower-boiling liquids.
- Condensers Double Surface Davies — water-cooled on an inner and an outer surface.
- Bends - Recovery, Sloping — joins a flask to a condenser set at a slope.
- Brass Condenser Clamp — chrome-plated brass clamp on a mild-steel rod.
Water-cooled types are listed with this one under Condensers, within Lab Glassware.
Request a Quote
Tell us the joint size, the quantity and where to deliver, using Add To Cart or the contact page.
