D.C. Compound Generator 2.5 KW Manufacturer,Supplier and Exporter in India
Product Code : EL-DSO-10314
Jlab Export is a leading D.C. Compound Generator 2.5 KW Manufacturer,and suppliers in India
D.C. Compound Generator 2.5 KW (code EL-DSO-10314) is a laboratory-type D.C. generator set for conducting machine experiments: a 2.5 kW, 230 V, 4-pole compound generator with a control desk whose instrument panel holds moving-coil meters, a DPST knife switch and HRC fuses. JLab (Jain Laboratory Instruments Pvt Ltd, Ambala, India) supplies it to schools, colleges and dealers.
Specifications
| Parameter | Detail |
|---|---|
| Generator | D.C. compound generator, self excited, horizontal foot mounted |
| Rating | 2.5 kW, 230 V, 1500 RPM, continuous rating |
| Poles | 4 |
| Insulation | Class B |
| Generator terminals | All terminals brought out to the terminal box |
| Control desk | Instrument panel above a working area; 30 x 30 x 1.6 mm tubular mild steel frame with 1 mm MS sheet, grey powder coated, wooden top on the working area; overall W 900 x D 625 x H 1500 mm |
| Instrument panel | Box type, W 900 x D 250 x H 750 mm; 6 mm brown bakelite front; other sides MS sheet with two sides perforated for ventilation; hinged, lockable back door |
| Working top | W 900 x D 375 mm in 19 mm marine plywood with a 3 mm ivory-colour top sheet and 22 x 6 mm teakwood lipping on three sides, at 750 mm from the bottom |
| Connections | 30 A educational-type bakelite-insulated banana terminals for the supply and generator; internal wiring with ferrules; panel circuit diagram inside the panel |
| Voltmeter | Moving coil, 0–300 V, 96 x 96 mm, Mars make (1 no.) |
| Ammeters | Moving coil, 0–15 A and 0–1.5 A, 96 x 96 mm, Mars make (1 no. each) |
| Field regulator | Disc type, to decrease the field current to a minimum (1 no.) |
| Switch | DPST knife switch, 20 A, mounted on the panel board (1 no.) |
| Indicating lamp | LED type, red, 12 mm (1 no.) |
| Fuses | HRC, bakelite base and top, 16 A, 230 V (2 nos.) |
| Base plate | Fabricated M.S. ‘C’ channel, 75 x 40 x 6 mm, 800 mm long for prime mover coupling |
| Finish | Generator and panel board painted with two coats of smoke grey oil paint |
| Quality check | Each generator set is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-DSO-10314 |
| Supplied by | Jain Laboratory Instruments Pvt Ltd (JLab), Ambala, India |
What Is the D.C. Compound Generator Used For?
A compound generator has two field windings: a shunt field across the armature and a series field that carries the load current. The way the series field adds to or works against the shunt field decides how the terminal voltage changes as load is applied, which is why compound, shunt and series machines are compared in the generator-characteristics experiments of an electrical machines lab.
Frequently Asked Questions
What does self-excited mean?
The generator feeds its own field windings from its armature output instead of from a separate supply. On starting, the small residual magnetism in the poles produces a little voltage, which drives field current, and the voltage builds up until it settles.
What is the field regulator used for on this generator?
It is a disc-type regulator in the shunt field circuit that can bring the field current down to a minimum. Lowering the field current lowers the voltage the generator produces at a given speed, so the output can be set across its range.
How does it relate to the Motor Shunt DC 220 Volt?
Both are laboratory machine sets with a control desk of the same construction and an 800 mm base plate — on this generator for prime mover coupling, on the motor for generator coupling. They are separate items and can be quoted together.
What should an export enquiry include?
The number of generator sets, the destination country and port or city, the delivery terms you prefer (for example FOB or CIF), any packing or labelling instructions, and the tender reference where there is one.
Who supplies this generator set?
JLab — Jain Laboratory Instruments Pvt Ltd of Ambala, Haryana — supplies it and handles the quotation for colleges, dealers and importers.
Supplier
JLab is the trading name of Jain Laboratory Instruments Pvt Ltd, incorporated in 2017 and based on Hargolal Road, Ambala, Haryana, India. The company supplies this compound generator set, whose panel meters are Mars make, together with its own electrical and electronics lab equipment, so a machines lab can source its generator, motor sets and trainers on one order. JLab exports worldwide and ships to buyers in every region — for example the USA in North America, Albania in Southern Europe, South Korea in East Asia, Kuwait in the Middle East and Tonga in Oceania. For tenders, see the JLab lab tenders page.
Related Machine Sets and Trainers
- Motor Shunt DC 220 Volt — a 3 HP D.C. shunt motor set with a three-point starter and field regulator.
- Motor Generator Trainer — a DC motor coupled to a second machine, one option being a DC generator.
- A.C. Squirrel Cage Induction Motor 3 Hp with D.O.L — a three-phase squirrel cage induction motor set with a D.O.L. starter.
More equipment is listed in the Electronics Lab Equipments range.
Request a Quote
Ask for a quotation with the Add To Cart button, or through the contact page, stating how many generator sets you need and where they are to be delivered.
