Motor Shunt DC 220 Volt Manufacturer,Supplier and Exporter in India
Product Code : EL-DSO-10313
Jlab Export is a leading Motor Shunt DC 220 Volt Manufacturer,and suppliers in India
Motor Shunt DC 220 Volt (code EL-DSO-10313) is a laboratory D.C. shunt motor set — a 3 HP, 220 V motor on a fabricated base plate together with a control desk — for experiments in the electric machines lab. The desk’s instrument panel carries a three-point starter, a field regulator and moving-coil meters. JLab (Jain Laboratory Instruments Pvt Ltd, Ambala, India) supplies it to schools, colleges and dealers.
Specifications
| Parameter | Detail |
|---|---|
| Motor | D.C. shunt motor, S.P.D.P. (screen protected drip proof) type, horizontal foot mounted |
| Motor rating | 3 HP, 220 V, 1500 RPM, continuous rating |
| Insulation | Class B |
| Motor terminals | All terminals brought out to the terminal box |
| Control desk | Instrument panel above a working area; frame of 30 x 30 x 1.6 mm tubular mild steel with 1 mm MS sheet, grey powder coated, wooden top on the working area |
| Desk overall size | W 900 x D 625 x H 1500 mm |
| Instrument panel | Box type, W 900 x D 250 x H 750 mm; front of 6 mm brown bakelite sheet; other sides MS sheet, two of them perforated for ventilation; hinged back door with locking arrangement |
| Working top | W 900 x D 375 mm, 19 mm marine plywood with a 3 mm ivory-colour top sheet, lipped on three sides with 22 x 6 mm teakwood; fitted 750 mm above the bottom of the desk |
| Connections | 30 A educational-type bakelite-insulated banana terminals for the supply and motor; internal wiring with ferrules; circuit diagram provided inside the panel |
| Starter | Three-point D.C. starter, flush mounted (1 no.) |
| Switch | D.P.S.T. knife switch (1 no.) |
| Indicating lamps | LED type, 12 mm, for incoming and outgoing supply (2 nos.) |
| Voltmeter | Moving coil, 0–300 V DC, 96 x 96 mm, Mars make (1 no.) |
| Ammeters | Moving coil, 0–15 A DC and 0–1.5 A DC, 96 x 96 mm, Mars make (1 no. each) |
| Field regulator | To keep the motor at constant rated RPM at full load (1 no.) |
| Base plate | Fabricated M.S. ‘C’ channel, 75 x 40 x 6 mm, 800 mm long for generator coupling |
| Finish | Motor: two coats of smoke grey oil paint; panel board and angle stand powder coated |
| Quality check | Each motor set is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-DSO-10313 |
| Supplied by | Jain Laboratory Instruments Pvt Ltd (JLab), Ambala, India |
What Is the D.C. Shunt Motor Set Used For?
In a D.C. shunt motor the field winding is connected in parallel with the armature, so on a steady supply the field current stays fixed and the speed falls only a little as the load increases. That near-constant speed makes the shunt motor the usual machine for speed-control and load-characteristic experiments in an electric machines lab.
Frequently Asked Questions
Why does a D.C. shunt motor need a starter?
At standstill there is no back EMF, so only the small armature resistance would limit the current. A three-point starter puts resistance in series with the armature while the motor runs up to speed and cuts it out in steps, and it also protects against the field circuit opening.
What does the field regulator do?
It sets the current in the shunt field winding. On this set it is there to keep the motor at its rated speed when fully loaded; reducing the field current raises the speed of a shunt motor.
What does S.P.D.P. mean on the motor?
Screen protected drip proof: the ventilation openings are covered by screens and the enclosure keeps out water falling from above, while cooling air can still pass through the machine.
How does it relate to the D.C. Compound Generator 2.5 KW?
Both are laboratory machine sets on a control desk of the same construction, each with a base plate 800 mm long — on this motor for generator coupling, on the generator for prime mover coupling. They are separate items that can be quoted on the same enquiry.
What information is needed for an export quotation?
Give the number of motor sets, the destination country and port or city, your preferred delivery terms (for example FOB or CIF), any packing or labelling needs, and the tender reference if the order is for a tender.
Who supplies this motor set?
Jain Laboratory Instruments Pvt Ltd (JLab), Ambala, supplies it and quotes for it directly to schools, colleges, dealers and importers.
Supplier
JLab is the trading name of Jain Laboratory Instruments Pvt Ltd, a laboratory equipment company in India, incorporated in 2017 and based on Hargolal Road, Ambala, Haryana. This D.C. shunt motor set, with its Mars make meters, is supplied by JLab alongside its own range of electrical and electronics lab equipment, so a machines lab can order its motor, generator and trainer benches from one source. JLab exports worldwide and ships to buyers in every region — for example Algeria in North Africa, Liberia in West Africa, Turkmenistan in Central Asia, Kenya in East Africa and Poland in Eastern Europe. Tender information is on the JLab lab tenders page.
Related Electrical Machine Sets and Trainers
- D.C. Compound Generator 2.5 KW — a self-excited D.C. compound generator set on a control desk.
- A.C. Squirrel Cage Induction Motor 3 Hp with D.O.L — a three-phase squirrel cage induction motor set with a D.O.L. starter.
- Motor Generator Trainer — a DC motor coupled to a second machine, with its panels in an aluminium profile rack.
- Brushless DC Motor Trainer — a brushless DC motor run from an electronic controller panel.
- Thyristor/IGBT Controlled AC Motor With VVVF Control — a setup with a thyristor/IGBT AC drive for starting and controlling an AC motor.
Browse the wider Electronics Lab Equipments range for more trainers and instruments.
Request a Quote
Use the Add To Cart button on this page, or send the number of motor sets, the delivery location and any other machines you need through the contact page.
