Analog Lab Trainer with Bread Board Manufacturer,Supplier and Exporter in India
Product Code : EL-DSO-10319
Jlab Export is a leading Analog Lab Trainer with Bread Board Manufacturer,and suppliers in India
Analog Lab Trainer with Bread Board (code EL-DSO-10319) is a bench trainer on which students build and test analog electronic circuits, with power supplies, a function generator and other input signals on board. It is designed for more than 50 analog electronics experiments. It is made by Jain Laboratory Instruments Pvt Ltd (JLab) at its works in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Experiments | More than 50 analog electronics experiments |
| Modules | Compatible with optional ready-to-use experimental modules |
| Front panel | Glass epoxy PCB, 300 x 220 mm, on a lightweight shock-proof plastic cabinet |
| DC regulated power supplies | +5 V DC / 1 A; +12 V DC / 500 mA; 0 to +15 V DC / 500 mA |
| AC power supply | 9-0-9 V / 500 mA |
| Function generator | Sine, square and triangular; 1 Hz to 100 kHz; adjustable amplitude |
| Modulation/audio generator | Sine, square and triangular; 1 Hz to 10 kHz; adjustable amplitude |
| Continuity tester | With beeper sound |
| Breadboard | 2 vertically common strips of 640 tie points each; 4 horizontally common strips of 100 tie points each |
| Power requirement | 230 V AC 10%, 50 Hz |
| Dimensions | 300 (L) x 175 (B) x 75 (H) mm |
| Standard accessories | 5 m hook-up wire; 20 patch cords with a 2 mm banana plug on one end; power cord; instruction manual |
| Quality check | Each trainer is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-DSO-10319 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
How Does It Compare with Other JLab Analog Breadboard Trainers?
| Trainer | Function generator | Power supplies |
|---|---|---|
| This trainer (EL-DSO-10319) | 1 Hz to 100 kHz, plus a 1 Hz to 10 kHz modulation/audio generator | +5 V/1 A, +12 V/500 mA and 0 to +15 V/500 mA DC; 9-0-9 V/500 mA AC |
| Analog Lab | 1 Hz to 110 kHz in 5 steps, variable between steps | +5 V and −5 V at 1 A; +12 V/0 to 20 V and −12 V/0 to −20 V at 500 mA DC; 5-0-5 V and 10-0-10 V at 100 mA AC |
| Analog and Digital Trainer Bread Board Type | 1 Hz to 250 kHz | ±5 V; ±15 V fixed; variable supply |
The three differ most in signal range and supply rails: this trainer’s main generator reaches 100 kHz and its DC supplies are positive rails up to +15 V, the Analog Lab’s generator reaches 110 kHz with paired positive and negative rails, and the Analog and Digital Trainer’s reaches 250 kHz with ±5 V and ±15 V supplies.
What Is the Analog Lab Trainer Used For?
Students assemble circuits on the breadboard from loose components, power them from the on-board supplies and drive them with the generators, so practicals such as diode and transistor circuits, amplifiers, oscillators, filters and wave-shaping circuits can be built and changed without soldering.
Frequently Asked Questions
What is the modulation/audio generator for?
It is a second signal source, 1 Hz to 10 kHz with sine, square and triangular outputs, that can supply the audio or modulating signal in modulation experiments or a second test input while the main function generator is in use.
How is the breadboard laid out?
It has two vertically common strips of 640 tie points each for the circuit itself and four horizontally common strips of 100 tie points each, which are handy as supply and ground rails.
Can experiment modules be used with it?
Yes. The trainer is compatible with optional ready-to-use experimental modules; they are separate items that can be quoted on the same enquiry.
What information is needed for an export quotation?
Send the number of trainers, the destination country and port or city, your preferred delivery terms (for example FOB or CIF), any packing or labelling requirements, and a tender reference if one applies.
Who manufactures this trainer?
Jain Laboratory Instruments Pvt Ltd, trading as JLab, makes it at its works in Ambala, Haryana, and quotes for it directly.
OEM Manufacturer
JLab is the trading name of Jain Laboratory Instruments Pvt Ltd, an electronics lab equipment manufacturer in India, incorporated in 2017 and based on Hargolal Road, Ambala, Haryana. The trainer is produced at JLab’s own works rather than sourced from a trader, so schools, colleges, dealers and importers order it directly from the maker and repeat orders are handled by the same team. JLab exports worldwide and ships to buyers in every region — for example Tonga in Oceania, Guyana in South America, Burkina Faso in West Africa, Turkey in the Middle East and Gabon in Central Africa. Tender information is on the JLab lab tenders page.
Related Analog Electronics Trainers
- Analog Lab — an analog trainer with DC regulated supplies, a function generator, a digital meter and a continuity tester.
- Analog and Digital Trainer Bread Board Type — a breadboard trainer for analog and digital circuits, with a clock pulse and logic input and output.
- Operational Amplifier Trainer — for studying op-amp inverting, non-inverting, summing and difference amplifiers.
- Transistor Characteristics Apparatus — for plotting the input, output and transfer characteristics of PNP and NPN transistors.
Browse the Breadboard Trainers and Analog Electronics Trainer ranges, or the full Electronics Lab Equipments range.
Request a Quote
Use the Add To Cart button, or send the number of trainers, any experiment modules and the delivery location through the contact page.
