Diesel Engine Test Bed Manufacturer,Supplier and Exporter in India
Product Code : EL-AELE-9381
Jlab Export is a leading Diesel Engine Test Bed Manufacturer,and suppliers in India
This test bed puts a complete four-stroke, four-cylinder diesel engine and its matching transmission on a powder-coated tubular steel frame. A 10 litre tank feeds the fuel filter, fuel pump and injection system, and a 12 V battery is provided. The clutch lever and shift mechanism work as in a vehicle, and operation and experiment manuals are included.
Specifications
| Engine | Diesel, 4 stroke, 4 cylinder |
| Transmission | Matching transmission with shifting mechanism and clutch operation lever |
| Fuel system | 10 litre tank connected to the fuel filter, fuel pump and fuel injection system |
| Battery | 12 V |
| Frame | Tubular steel, powder coated, with instrumentation and accessories |
| Manuals | Operation manuals and experiment manuals |
| Training use | Diagnosis, tune-up, fault finding and troubleshooting |
| Upgrade | Can connect to a modular dynamometer system |
| Minimum order quantity | 1 unit |
| Dispatch time | Usually 14–18 working days |
| Manufacturer | JLab (Jain Laboratory Instruments Pvt Ltd), Ambala, India |
Diesel Engine Practicals for Students
Fuel system work starts at the tank. Students follow the fuel through the filter and pump to the injection system, change a filter and bleed the air out afterwards. Injectors taken from the engine go on a Diesel Injector Tester, where students set the nozzle opening pressure and check leakage, spray pattern and chatter.
A compression test with the Diesel Engine Compression Tester, fitted through one of its adaptors, compares all four cylinders. Students also practise clutch operation and gear selection on the matching transmission. While the engine runs, an Engine Stethoscope helps them trace knocks and leaks to their source.
Frequently Asked Questions
What do white and black exhaust smoke mean on a diesel?
Black smoke is unburnt fuel, often from too much fuel for the air: a blocked air filter, a dribbling injector or overloading. White smoke is unburnt fuel mist or steam. It shows on a cold start, with late injection timing or low compression. White smoke with coolant loss can point to coolant entering a cylinder.
How is air bled from the fuel system?
After a filter change, loosen the bleed screw on the filter and work the priming pump until fuel comes out free of bubbles, then close it. Repeat at the injection pump bleed point. If the engine still will not start, loosen the injector unions slightly while cranking.
Why is a diesel hard to start in cold weather?
A diesel relies on hot compressed air to light its fuel. In the cold, the cylinder walls take heat from that air, the oil thickens and the battery cranks more slowly. Weak glow plugs, where fitted, make it worse, and diesel fuel can also thicken with wax in very cold weather.
What is supplied with the test bed?
The engine and matching transmission come on the tubular steel frame with the 10 litre fuel tank, filter, pump and injection system. A 12 V battery, instrumentation, accessories and the operation and experiment manuals are included.
How does it differ from the EFI petrol test bed?
A diesel ignites its fuel by compression, so there is no spark ignition system to test. The EFI Petrol Engine Test Bed suits ignition, fuel pressure and exhaust gas work, while this one centres on injection, compression and fuel bleeding.
Other Diesel Engine Equipment
- Multi Cylinder Four Stroke Water Cooled Diesel Engine Test Rig
- Fuel Supply System Diesel CRDI Type
- Vacuum and Fuel Pump Tester
For a quote, use Add To Cart or send us a message through the contact page.
