Digital Electronic Trainer Manufacturer,Supplier and Exporter in India
Product Code : EL-BT-1488
Jlab Export is a leading Digital Electronic Trainer Manufacturer,and suppliers in India
Digital Electronic Trainer (code EL-BT-1488) is a breadboard trainer for digital electronics practicals, with a spring-loaded solderless breadboard, an IC-regulated 5 V supply, fixed and variable clock generators, a bounceless manual pulser, and eight logic inputs and eight indicators. A 40-pin universal ZIF socket and a BCD to seven-segment decoder/driver are also provided. JLab, the trading name of Jain Laboratory Instruments Pvt Ltd, builds it in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Breadboard | Solderless, spring loaded; one terminal strip with 640 tie points and 2 distribution strips with 100 tie points each, 840 tie points in total; approx. 55 mm x 170 mm |
| DC power supply | 5 V ±0.25 V / 500 mA, IC-based regulated output |
| Clock generators | Fixed 0.1 Hz and 1 Hz (simultaneous independent outputs); one low-frequency variable clock generator |
| Manual pulser | One independent bounceless pulser |
| Logic level inputs | Eight independent inputs selecting High/Low TTL levels, each with an LED for high/low status, and terminations |
| Logic level indicators | Eight independent buffered indicators for the high/low status of digital outputs |
| Seven-segment decoder | One BCD to seven-segment decoder/driver IC, with terminations |
| Continuity tester | Audio and visual indication |
| ZIF socket | Universal ZIF socket for ICs up to 40 pins, without soldering |
| Potentiometer | One, 100 k, with terminations |
| Power switch | Power ON switch with mains-on indicator; fuse for protection |
| Patch cords | 20 assorted coloured multi-strand wires with 2 mm stackable plugs at both ends |
| Instruction manual | One detailed manual with experiments covering these topics |
| Power requirement | 230 V single-phase AC (+10%) |
| Quality check | Each trainer is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-BT-1488 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
How Does It Compare with Other JLab Breadboard Trainers?
| Trainer | Breadboard | DC supplies |
|---|---|---|
| This Digital Electronic Trainer (EL-BT-1488) | 840 tie points | 5 V ±0.25 V at 500 mA |
| Bread Board Circuit Lab | 1680 tie points | ±12 V at 500 mA, each also variable from 0; fixed +5 V at 500 mA |
| Digital Trainer | 1680 tie points | Fixed +5 V at 750 mA |
Choose the Digital Electronic Trainer when a smaller breadboard and a single 5 V supply are enough for the circuits; the Bread Board Circuit Lab offers a breadboard twice the size and ±12 V rails as well as 5 V.
What Is the Digital Electronic Trainer Used For?
It supports the digital electronics practicals of diploma, degree and ITI courses, including counter and display-decoding circuits. Circuits are built on the breadboard, inputs are set with the logic level inputs and results are read on the buffered indicators.
What to Specify When Ordering
- Quantity — the number of trainers for the lab.
- Mains supply — the trainer takes 230 V single-phase AC; check this against the supply at the place of use.
- Other trainers — the trainers compared above and linked below are separate items that can be added to the same enquiry.
Frequently Asked Questions
What is the ZIF socket for?
A zero insertion force (ZIF) socket opens its contacts with a lever, so ICs can be dropped in, clamped and removed again without force, bent pins or soldering.
What clock sources are there?
Fixed 0.1 Hz and 1 Hz clocks, available together as independent outputs, and one low-frequency variable clock generator. For step-by-step work the bounceless manual pulser freezes the action of each counter stage after every pulse.
What does the BCD to seven-segment decoder/driver do?
It converts a binary-coded decimal (BCD) input into the signals that light the right segments of a seven-segment display for each decimal digit, so counter outputs can be shown as numbers.
What is supplied with the trainer?
Twenty multi-strand patch cords with 2 mm stackable plugs at both ends and a detailed instruction manual.
What details does an export quotation need?
The quantity, the destination country and port or city, the delivery terms you prefer (for example FOB or CIF), any packing or labelling requirements and a tender reference where there is one.
Who makes the Digital Electronic Trainer?
Jain Laboratory Instruments Pvt Ltd (JLab) manufactures it at its works in Ambala, Haryana, India.
OEM Manufacturer
JLab is the trading name of Jain Laboratory Instruments Pvt Ltd, a manufacturer in India of digital electronic trainers, breadboard labs and other educational laboratory equipment, incorporated in 2017 and based on Hargolal Road, Ambala, Haryana. The Digital Electronic Trainer comes from JLab’s own works, not from a trader, so colleges, ITIs, dealers and importers order it directly from the maker and get repeat orders and spares from the same source. The company is registered under CIN U29309HR2017PTC069123 and holds MSME Udyam registration UDYAM-HR-01-0003849 as a manufacturing enterprise. JLab exports worldwide and ships to buyers in every region — for example Malaysia in Southeast Asia, Japan in East Asia, Croatia in Southern Europe, Germany in Western Europe and Chad in Central Africa. Tender information is on the JLab lab tenders page.
Related Digital Trainers
- Logic Lab — a logic trainer with on-board gate units, debounced switches, an LED indicator and a pulse generator.
- Digital Lab — a breadboard trainer whose experiments include code converters, encoders, decoders, counters and a shift register.
Browse all Breadboard Trainers in Electronics Lab Equipments.
Request a Quote
Ask for a quotation with the Add To Cart button on this page or the contact page, telling us the number of trainers, the delivery destination and any other trainers to include.
