Microprocessor Board (LCD Variant) Manufacturer,Supplier and Exporter in India
Product Code : EL-PET-10187
Jlab Export is a leading Microprocessor Board (LCD Variant) Manufacturer,and suppliers in India
Microprocessor Board (LCD Variant) (code EL-PET-10187) is an 8085 microprocessor trainer that is worked through an ASCII keyboard and a backlit alphanumeric LCD. An on-board single-line assembler/disassembler lets students write programs as mnemonics. JLab (Jain Laboratory Instruments Pvt Ltd) manufactures the board in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| CPU | 8085, operating at 6.144 MHz |
| RAM | 8 KB, with battery backup |
| Monitor EPROM | 8K |
| Display | 20x2 alphanumeric LCD with backlight |
| Keyboard | 101-key ASCII keyboard |
| On-board software | Single-line assembler/disassembler |
| Built-in power supply | +5 V / 1.5 A; ±12 V / 250 mA |
| Quality check | Each board is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-PET-10187 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
What Is the LCD Microprocessor Board Used For?
It is used to teach 8085 assembly-language programming and how a CPU, its memory and a monitor program work together. Because the LCD shows text rather than single digits, mnemonics, addresses and data can be read as plain characters, and the battery backup keeps a program in RAM after power is switched off.
Frequently Asked Questions
What does the single-line assembler/disassembler do?
It turns an 8085 instruction typed as a mnemonic into machine code one line at a time, and turns machine code in memory back into mnemonics, so programs can be written and checked without hand-coding hexadecimal.
How does it differ from the LED variant?
Both are 8085 boards operating at 6.144 MHz with battery-backed RAM, an 8K monitor EPROM and +5 V / 1.5 A and ±12 V / 250 mA supplies. This board has a 20x2 backlit LCD and a 101-key ASCII keyboard; the Microprocessor Board (LED Variant) has a 28-key keyboard and six seven-segment LED displays.
What should an export enquiry include?
The number of boards, the destination country and port or city, delivery terms such as FOB or CIF, and any tender reference.
OEM Manufacturer
JLab is the trading name of Jain Laboratory Instruments Pvt Ltd, an Indian manufacturer of electronics trainers and laboratory equipment, incorporated in 2017 and based on Hargolal Road, Ambala, Haryana. The board comes from JLab’s own works rather than a trader, and schools, colleges, dealers and importers buy it factory-direct. JLab exports worldwide and ships to buyers in every region — for example Bangladesh in South Asia, Qatar in the Middle East, Tanzania in East Africa, Gabon in Central Africa and Estonia in Northern Europe. Tender details are on the JLab lab tenders page.
Related Microprocessor Trainers
- 8085 Microprocessor Training Kit — programmable I/O lines and an 8253 timer/counter.
- Microprocessor Trainer — an 8086 or 8088 trainer with an 8087 numeric data processor.
- Microcontroller board, LED variant — 8K user RAM with battery backup and a 16K-byte monitor EPROM.
See the Power Electronics Trainers category, the Microprocessors range or all Electronics Lab Equipments.
Request a Quote
Ask for a quotation through the Add To Cart button on this page or the contact page, with the quantity and the delivery city and country.
