Refrigeration Liquid Bath and Cooling Bath Manufacturer,Supplier and Exporter in India
Product Code : EL-B-1963
Jlab Export is a leading Refrigeration Liquid Bath and Cooling Bath Manufacturer,and suppliers in India
A refrigeration liquid bath cools as well as heats, so it can hold a liquid below room temperature or well above it. This double-walled bath covers 5 °C to 90 °C. A mercury contact thermometer controls it to ±2 °C, and a stirrer with a speed regulator keeps the 32 litre chamber at one temperature.
Specifications
| Construction | Double walled |
| Temperature range | 5 °C to 90 °C |
| Control | Mercury contact thermometer, ±2 °C |
| Stirring | Stirrer with speed regulator |
| Finish | Stainless, corrosion resistant, light in weight |
| Chamber size | 500 x 250 x 250 mm, 32 litres |
| Minimum order quantity | 1 unit |
| Dispatch time | Usually 7–10 working days |
| Manufacturer | JLab (Jain Laboratory Instruments Pvt Ltd), Ambala, India |
Solubility and Reaction Rate Experiments
A standard school and college experiment plots the solubility curve of a salt such as Potassium Nitrate. Students stir excess salt with water in Laboratory Test Tubes held in the bath at several settings, from cool to hot. A weighed portion of each clear solution is evaporated in a China Dish (3 Inch), and the dry salt is weighed to find how much dissolved at that temperature.
The same bath lets a class time the reaction of sodium thiosulphate with dilute acid at settings both below and above room temperature. Students watch a cross under the flask disappear and plot the time against temperature.
Frequently Asked Questions
When do I need a cooling bath rather than a heated one?
Whenever the setting is near or below room temperature. A heated bath can only add heat, so on a warm day it cannot hold a cool setting. The refrigeration unit here removes heat and holds settings down to 5 °C.
How close to the setting does it hold?
The mercury contact thermometer keeps the liquid within about 2 °C of the setting. Where results need closer readings, hang a separate thermometer in the liquid next to your samples and note its value with each result.
What speed should the stirrer run at?
Fast enough that the liquid moves past every vessel, but slow enough not to splash or rock the tubes. A brisk speed helps while the bath is cooling, because cold liquid near the cooling surfaces must be mixed into the rest.
What liquid goes in the bath?
Water serves across the whole 5 °C to 90 °C range, so no antifreeze is needed. Use distilled water to limit scale on the heater and cooling surfaces, and keep the level above them.
How many vessels fit in the chamber?
The 500 x 250 x 250 mm chamber holds 32 litres, enough for several racks of tubes or a row of flasks. Leave gaps between them so the stirred liquid reaches each one.
Other Cooling and Circulating Baths
- Refrigerated Water Bath (digital controller, insulated hinged lid)
- Chiller Water Bath (for settings below zero)
- Refrigerated Circulating Liquid Bath
For a quote, use Add To Cart or send us a message through the contact page.
