Disc Sander Belt Manufacturer,Supplier and Exporter in India

Disc Sander Belt

Product Code : EL-WWM-8629
Jlab Export is a leading Disc Sander Belt Manufacturer,and suppliers in India

A sanding belt and a sanding disc share one motor on this bench machine. The adjustable 4 x 36 in belt sands flat work and both inside and outside curves. The 6 in disc takes the smaller pieces. One cast aluminium table serves either side and tilts from 0° to 60°, and the motor runs on 120 V.

Specifications

Belt4 x 36 in, one 80 grit belt included
Disc6 in diameter, one 80 grit disc included
Motor120 V, 1/2 HP rated, 3/4 HP peak
Disc speed1780 rpm
Belt speed1150 FPM (feet per minute)
TableCast aluminium, tilts 0° to 60°, moves between belt and disc
Mitre gauge0° to 60° left and right
ConstructionCast aluminium disc, cast iron motor housing, toggle switch
Overall size (H x W x D)24-3/4 x 15 x 14 in
Weight37.5 lb
Minimum order quantity1 unit
Dispatch timeUsually 14–18 working days
ManufacturerJLab (Jain Laboratory Instruments Pvt Ltd), Ambala, India

Workshop Practice on the Belt and Disc

After cutting a curved bracket or a toy shape with Coping Saws, students sand the outside curve on the flat run of the belt. Inside curves go against the round end of the belt, where it wraps over its roller. The finished edge is then checked against a Square to see that it stayed square to the face.

On the disc, students square the ends of short rails with the mitre gauge at 0°. Then they angle the gauge to sand the corner mitres of a small picture frame. Tilting the table gives a bevel instead. A final pass by hand with a Sanding Block takes out the cross-grain marks.

Frequently Asked Questions

Which side of the disc should I sand on?
Use the half of the disc that moves down towards the table. It presses the work onto the table as it cuts. On the other half the disc tries to lift the piece and throw it upwards.

What grit comes with it, and when should I change it?
It comes with one 80 grit belt and one 80 grit disc. That grit shapes quickly and removes saw marks. For a smoother face, move on to a finer belt or disc, or finish by hand. Replace a belt once it glazes or stops cutting.

Why does the belt run off to one side?
The belt is tracking off centre. With the machine unplugged, turn the belt by hand and adjust the tracking until it runs in the middle of the rollers, then check it under power. Fit each belt with the arrow on its back pointing the way the belt runs. Clean dust off the rollers and replace a stretched or torn belt.

How much bench space does it need?
It stands 24-3/4 in high, 15 in wide and 14 in deep and weighs 37.5 lb. A solid bench takes it easily. Fix or clamp the base down so the machine cannot creep while you press work against the belt.

Other Sanders in the Range

For a quote, use Add To Cart or send us a message through the contact page.
