Open Wind Tunnel Apparatus Manufacturer,Supplier and Exporter in India
Product Code : EL-TL-10068
Jlab Export is a leading Open Wind Tunnel Apparatus Manufacturer,and suppliers in India
Open Wind Tunnel Apparatus (code EL-TL-10068) is an open wind tunnel that draws room air through a shaped nozzle and flow straightener into a closed, transparent measuring section of square cross-section, at air velocities up to 28 m/s. An electronic two-component force sensor shows lift and drag digitally, and an inclined tube manometer shows the air velocity. JLab builds the wind tunnel in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Type | Open wind tunnel; air drawn from and returned to the room |
| Measuring section | Closed, transparent, square cross-section |
| Air velocity | Up to 28 m/s |
| Fan | Axial fan with guide vane and variable-speed drive |
| Flow conditioning | Shaped nozzle contour and flow straightener |
| Force measurement | Electronic two-component sensor; lift and drag shown digitally |
| Velocity reading | Inclined tube manometer |
| Instructional material | Fundamentals and step-by-step experiment guide |
| Quality check | Each wind tunnel is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 1 unit |
| Dispatch time | Usually 14–18 working days |
| Product code | EL-TL-10068 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
Air Path Through the Tunnel
The model stays at rest while the air moves past it. Room air is accelerated in the nozzle, whose contour, together with the flow straightener, gives a uniform velocity with little turbulence in the measuring section. After passing the model, for example an aerofoil, the air is slowed in a diffuser and the axial fan returns it to the room. The guide vane and variable-speed drive of the fan set the test velocity.
From Readings to Lift and Drag Coefficients
The manometer reading gives the dynamic pressure q = ½ρV², so the air velocity is V = √(2q/ρ). Dividing the measured lift L and drag D by q and a reference area A of the model gives the coefficients CL = L/(qA) and CD = D/(qA). The instructional material sets out these fundamentals and guides students step by step through drag and lift coefficients for different models, pressure distribution around drag bodies, boundary layer analysis, investigation of flutter and wake measurement. With the accessories, streamlines can also be visualised, and tube manometers are recommended for pressure curves on drag bodies.
Related Flow and Pressure Measurement Apparatus
- Wind Tunnel Test Rig — open-type wind tunnel rig driven by an AC induction motor.
- Pitot Static Tube Set-Up — Pitot tube calibration and velocity profiles in a water pipe.
- Manometer — U-tube glass manometer with stopcock on a backing plate.
The tunnel is part of Thermodynamics Lab in Fluid Mechanics and Hydraulics Lab Equipment.
