Pelton Wheel Turbine Test Rig Manufacturer,Supplier and Exporter in India
Product Code : EL-HLE-8977
Jlab Export is a leading Pelton Wheel Turbine Test Rig Manufacturer,and suppliers in India
Pelton Wheel Turbine Test Rig (code EL-HLE-8977) is a test rig for a small Pelton wheel, the impulse turbine used for high head at low discharge, coupled to a rope brake dynamometer. It is rated at 5 HP and 1000 rpm, with a supply head of 50 m, a discharge capacity of 750 litres per minute and gun metal buckets. JLab builds this Pelton turbine rig in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Turbine | Small Pelton wheel with gun metal buckets |
| Capacity | 5 HP |
| Rated speed | 1000 rpm |
| Discharge capacity | 750 litres/minute |
| Supply head | 50 m |
| Loading | Rope brake dynamometer |
| Brake drum | Cast iron, 300 mm diameter |
| Quality check | Each turbine test rig is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 1 unit |
| Dispatch time | Usually 14–18 working days |
| Product code | EL-HLE-8977 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
Measuring Output and Efficiency
Water leaves the nozzle as a free jet at a velocity close to √(2gH), and the buckets turn it back to take up its momentum. The hydraulic input is ρ g Q H. The rope brake on the 300 mm cast iron drum loads the shaft: with W and S the tensions on the tight and slack ends of the rope, the brake torque T is (W − S) times the effective drum radius, and the brake power is T ω at shaft speed ω in rad/s. Efficiency is the brake power divided by the hydraulic input.
Characteristic Curves at Constant Head
Tightening the rope brake step by step at a fixed supply head slows the wheel and gives curves of brake power and efficiency against speed. Efficiency peaks when the bucket speed is close to half the jet speed, because the water then leaves the buckets with the least kinetic energy left in it.
Other Turbine and Jet Apparatus
- Pelton Wheel Turbine Test Setup — SS nozzle with spear control and an acrylic window onto the buckets.
- Francis Turbine Test Rig — inward-flow reaction turbine with aerofoil gun metal guide vanes.
- Kaplan Turbine Test Rig — reaction turbine whose input is read by orifice meter and pressure gauge.
- Impact of Jet Apparatus — the jet-on-vane momentum principle behind the buckets.
Turbine and pump rigs are found in Hydrology Lab Equipments, part of Mechanical Engineering Lab Equipment.
Request a Quote
Send your enquiry by Add To Cart or the contact page with the number of rigs and the delivery location, and a quotation is returned.
