Reynolds Apparatus Manufacturer,Supplier and Exporter in India
Product Code : EL-HLE-8974
Jlab Export is a leading Reynolds Apparatus Manufacturer,and suppliers in India
Reynolds Apparatus (code EL-HLE-8974) is a flow-visualisation rig for the Osborne Reynolds experiment, in which dye from a stainless steel vessel enters water flowing in a borosilicate glass tube through a copper or stainless steel capillary. A 40 litre constant head tank, a 60 litre sump and an FHP pump handle the water. JLab manufactures this dye-trace Reynolds rig in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Test tube | Borosilicate glass |
| Dye vessel | Stainless steel |
| Capillary tube | Copper or stainless steel |
| Constant head water tank | 40 litres |
| Sump tank | 60 litres |
| Water circulation | FHP pump |
| Stop watch | Electronic |
| Control panel | On/off switch and mains indicator |
| Power supply required | Single phase, 200/220 V |
| Water required | To fill the sump tank |
| Quality check | Each Reynolds apparatus is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 1 unit |
| Dispatch time | Usually 14–18 working days |
| Product code | EL-HLE-8974 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
Reading the Dye Trace
The Reynolds number Re = ρ v D / μ compares inertia with viscous forces, where v is the mean velocity in a tube of bore D and μ the dynamic viscosity of the water. At low flow the dye stays a straight, unbroken thread: the flow is laminar, which in a pipe holds below about Re 2000. As the flow rate is raised the thread wavers and breaks, and above about Re 4000 the dye mixes across the whole bore as the flow turns turbulent. The mean velocity is the discharge Q, timed with the electronic stop watch, divided by the bore area.
Why the Constant Head Tank Matters
The 40 litre constant head tank holds the supply level steady, so the flow in the glass tube does not surge with the pump. The dye trace then reflects the flow regime at that rate alone, and each reading of Re can be repeated.
Other Reynolds and Pipe Flow Apparatus
- Reynolds Apparatus — bell-mouth glass tube with an outlet cock and a measuring cylinder.
- Reynolds Apparatus — vertical precision-bore glass pipe in a shroud, with a heater module.
- Friction in Pipe Lines Apparatus — two GI pipes in parallel for Darcy-Weisbach friction factor tests.
The rig is grouped with the Hydrology Lab Equipments of Mechanical Engineering Lab Equipment.
