Hydraulic Ram Test Rig Manufacturer,Supplier and Exporter in India
Product Code : EL-HLE-8980
Jlab Export is a leading Hydraulic Ram Test Rig Manufacturer,and suppliers in India
Hydraulic Ram Test Rig (code EL-HLE-8980) is a test rig for a 50 × 15 mm hydraulic ram that lifts water against a delivery head of up to 20 m from a supply head of 2.5 m, discharging about 250 LPH at a 10 m head. A 0.5 HP single-phase pump keeps the supply tank filled from the sump, and a 50 mm drive pipe 6 m long feeds the ram. This hydraulic ram rig is made by JLab in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Hydraulic ram | 50 × 15 mm |
| Supply head | 2.5 m |
| Delivery head | Up to 20 m |
| Delivery | About 250 LPH at 10 m head |
| Supply (drive) pipe | 50 mm, 6 m long, supply tank to ram |
| Delivery pipe | ½ in, ram to measuring tank |
| Pump | 0.5 HP, single phase, sump to supply tank |
| Quality check | Each hydraulic ram rig is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 1 unit |
| Dispatch time | Usually 14–18 working days |
| Product code | EL-HLE-8980 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
How the Ram Lifts Water
Water runs down the drive pipe and escapes through the ram’s waste valve until its speed is high enough to slam the valve shut. The sudden stop creates a water-hammer pressure rise that opens the delivery valve and pushes a small quantity of water up the ½ in delivery pipe; as the pressure wave dies away, the delivery valve closes, the waste valve reopens and the cycle starts again. No outside power drives the ram itself: a large flow falling through a small head lifts a small flow through a large one.
Efficiency and Lift Ratio
With q the useful water delivered, Q the waste water, H the supply head and h the delivery head, both heads measured from the ram, the Rankine efficiency is η = q (h − H) / (Q H), and D’Aubuisson’s form is q h / ((Q + q) H). At the rated 10 m head the ram lifts water four times higher than its 2.5 m supply head; raising the delivery head towards 20 m cuts the delivered flow, and the measuring tank shows by how much.
Other Pump Test Rigs
- Hydraulic Ram Test Setup — pulse valve with adjustable closing pressure and an air vessel.
- Reciprocating Pump Test Rig — double-acting piston pump with air vessel, driven by crank and connecting rod.
- Centrifugal Pump Test Rig — pump run at three speeds by stepped pulley, input read on an energy meter.
- Gear Oil Pump Test Rig — positive-displacement gear pump on a DC drive with digital rpm indicator.
Further pump and turbine rigs are kept in Hydrology Lab Equipments, a section of Mechanical Engineering Lab Equipment.
Request a Quote
Enquire through Add To Cart or the contact page, giving the quantity and the delivery address, for a quotation on the ram rig.
