Vernier Caliper 0-300 mm Manufacturer,Supplier and Exporter in India
Product Code : EL-PLEA-13381
Jlab Export is a leading Vernier Caliper 0-300 mm Manufacturer,and suppliers in India
Vernier Caliper 0-300 mm (code EL-PLEA-13381) is a long-range stainless steel vernier caliper measuring from 0 to 300 mm with a reading of 0.1 mm or 0.05 mm. Its jaws, depth bar and step faces take outside and inside diameters, depths and steps, and a lock screw fixes the sliding jaw. JLab manufactures this 300 mm caliper in Ambala, India, for laboratories and industrial quality control.
Specifications
| Parameter | Detail |
|---|---|
| Material | Stainless steel |
| Measuring range | 0–300 mm |
| Reading | 0.1 mm or 0.05 mm |
| Measures | Outside diameter, inside diameter, depth and steps |
| Scales | Main scale and Vernier scale |
| Jaw lock | Lock screw holds the sliding jaw position |
| Quality check | Each caliper is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 1 unit |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-PLEA-13381 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
When the Longer Range Is Needed
A 300 mm beam spans work that a short caliper cannot reach across: wide beakers and containers, long rods and blocks, and larger machined parts checked during quality control. On long measurements, keep the beam square to the object and support its far end so the jaws sit flat, since a slight tilt along a long beam adds error to the reading.
Reading the Scales and Checking Zero
Whole millimetres come from the main scale up to the Vernier zero; the Vernier division that lines up exactly with a main-scale mark, times the least count of 0.1 mm or 0.05 mm, supplies the fraction. Before measuring, close the jaws and confirm that both zeros coincide. When the jaws are set in an awkward spot, tighten the lock screw and bring the caliper into good light to read it.
Related Measuring Instruments
- Vernier Caliper IME Type — another vernier caliper pattern for physics practicals.
- Micrometer Screw Gauge in mm — finer readings on small diameters and thicknesses.
- Meter Scale Steel — for lengths beyond the reach of a caliper.
Other measuring apparatus sits in Physics Lab Equipment Ambala.
Request a Quote
Add the caliper via Add To Cart or use the contact page, stating the quantity, the reading needed (0.1 mm or 0.05 mm) and the delivery location.
