Measurement of Inductance and Capacitance Manufacturer,Supplier and Exporter in India
Product Code : EL-AET-1472
Jlab Export is a leading Measurement of Inductance and Capacitance Manufacturer,and suppliers in India
Measurement of Inductance and Capacitance (code EL-AET-1472) is an analog electronics training board for measuring the value of an unknown capacitance and of an unknown inductance by a null method. Five unknown capacitors and three unknown inductors are selected by band switches, and a 1 kHz sine-wave oscillator with an audio amplifier and speaker for null detection is built in. The board is a JLab product, manufactured by Jain Laboratory Instruments Pvt Ltd in Ambala, India.
Specifications
| Parameter | Detail |
|---|---|
| Experiments | Measurement of the value of an unknown capacitance; measurement of the value of an unknown inductance |
| Unknown capacitors | Five values, selected by a band switch |
| Unknown inductors | Three values, selected by a band switch |
| Decade resistances | Two, in 100 Ω steps |
| Signal source | 1 kHz sine-wave oscillator |
| Null detector | Audio amplifier and speaker |
| Power supply | ±12 V DC at 100 mA, IC regulated, internally connected |
| Other components | Potentiometer; adequate number of other electronic components |
| Switch, protection and indicator | Mains ON/OFF switch, fuse and jewel light |
| Mains supply | 230 V ±10%, 50 Hz AC |
| Patch cords | Adequate number, stackable from the rear at both ends, 4 mm spring-loaded plugs, ½ metre long |
| Terminals | Terminals and sockets on the panel for connections and observation of waveforms |
| Operating instructions | Detailed, with the object, theory, design procedures, report suggestions and book references |
| Weight | About 3 kg |
| Dimensions | W 340 x H 110 x D 210 |
| Quality check | Each board is visually inspected before dispatch |
| Pack quantity | Each (sold individually) |
| Minimum order quantity | 10 units |
| Dispatch time | Usually 7–10 working days |
| Product code | EL-AET-1472 |
| Manufacturer | Jain Laboratory Instruments Pvt Ltd (JLab) — OEM |
| Country of origin | India (made in Ambala, Haryana) |
How Does It Compare with Other JLab Inductance and Capacitance Trainers?
| Model | Measures | Source | Null detector |
|---|---|---|---|
| This board (EL-AET-1472) | Unknown capacitance and unknown inductance; five capacitors and three inductors on band switches | Built-in 1 kHz sine-wave oscillator | Audio amplifier and speaker |
| Schering Bridge Trainer | Unknown capacitance by the Schering bridge; three unknown capacitors on a band switch | 1 kHz sine-wave oscillator | Audio amplifier with speaker |
| Anderson Bridge | Inductance of a given coil by the Anderson bridge; three inductances | 1 kHz sine-wave oscillator | Audio amplifier with speaker |
| Maxwell Inductance Capacitance Bridge | Inductance in terms of a standard capacitance | Built-in 1 kHz sine-wave source | Null detector with digital display |
Choose this board when one trainer should cover both an unknown capacitance and an unknown inductance, with several unknowns of each kind on band switches. The Schering Bridge Trainer measures capacitance by the Schering method, the Anderson Bridge measures the inductance of a coil, and the Maxwell Inductance Capacitance Bridge shows its null on a digital display.
What Is the Inductance and Capacitance Board Used For?
The board teaches how a null-balance measurement finds the value of a reactive component. The unknown capacitor or inductor is compared with known components at 1 kHz; the decade resistances are adjusted until the signal reaching the detector falls to a minimum, and the unknown value is then calculated from the known values. Because the out-of-balance signal is amplified and played through the speaker, the balance point is heard as the tone fading away. It is a standard experiment in BSc physics, electrical measurements and diploma electronics laboratories.
What to Specify When Ordering
- Model — this board or one of the other bridges compared above.
- Number of boards for the laboratory.
- Companion bridge trainers to be quoted on the same enquiry.
Frequently Asked Questions
Why is a speaker used as the null detector?
At 1 kHz the out-of-balance signal is a clearly audible tone. The audio amplifier makes even a small imbalance loud enough to hear, and as the circuit approaches balance the sound fades, so students can find the null by ear.
Why are several unknown capacitors and inductors provided?
With five capacitors and three inductors on band switches, students can measure a number of different components in one session and groups can be given different unknowns, which makes the practical more thorough and the results easier to check against one another.
How does it differ from the De Sauty Bridge?
The De Sauty Bridge compares two capacitances using decade resistances, decade capacitors and a headphone, with an external bridge oscillator. This board measures both unknown capacitance and unknown inductance, with its own 1 kHz oscillator and a speaker null detector.
What information is needed for an export quotation?
The number of boards, the destination country and port or city, delivery terms such as FOB or CIF, packing or labelling instructions, and the tender reference when buying for a tender.
Who manufactures this board?
Jain Laboratory Instruments Pvt Ltd, trading as JLab, makes it at its works in Ambala, Haryana, India.
OEM Manufacturer
JLab is the trading name of Jain Laboratory Instruments Pvt Ltd, an Indian manufacturer of physics apparatus, AC bridges and electronics trainers, incorporated in 2017 and based on Hargolal Road, Ambala, Haryana. This board is made at JLab’s own works rather than bought from a trader, so universities, colleges, dealers and importers order it from the maker directly; every board is visually inspected before dispatch, and repeat orders and spares are handled by the same works. JLab is registered under GSTIN 06AADCJ9848D1ZE and carries Legal Entity Identifier 549300DTGS77DGYD6N03. JLab exports worldwide and ships to buyers in every region — for example Luxembourg in Western Europe, Ukraine in Eastern Europe, Tanzania in East Africa, DR Congo in Central Africa and Libya in North Africa. Tender details are on the JLab lab tenders page.
Related Bridges and Instruments
- De Sauty Bridge — comparison of two capacitances with decade resistances, decade capacitors and a headphone null detector.
- Wien Bridge — capacitance measurement by the Wien series and Wien parallel bridges.
- L.C.R. Bridge — a fully solid-state bridge for measuring resistance, capacitance and inductance over wide ranges.
See the full Analog Electronics Trainer range or all Electronics Lab Equipments.
Request a Quote
Send an enquiry with the Add To Cart button or through the contact page, with the number of boards, the delivery destination and any other bridges you would like quoted with it.
