Slip Roller Machine Manufacturer,Supplier and Exporter in India

Slip Roller Machine

Product Code : EL-PWI-8826
Jlab Export is a leading Slip Roller Machine Manufacturer,and suppliers in India

A slip roll machine curves flat sheet into cylinders, cones and arcs by passing it between three rolls. This one rolls mild steel up to 16 gauge over a forming length of 49 in. Its 3 in rolls are high carbon steel, turned, ground and polished to resist wear. It is offered in manual and electric types.

Specifications

TypeManual or electric
CapacityMild steel, 16 gauge
Maximum forming length49 in
Roll diameter3 in
RollsHigh carbon steel, turned, ground and polished
Minimum forming radius1-1/2 in
Wire grooves3/8, 1/2 and 5/8 in
Gear ratio4:1
Roll speed22 RPM
Motor (electric type)3/4 hp, 230/460 V, 3 phase
Minimum order quantity1 unit
Dispatch timeUsually 14–18 working days
ManufacturerJLab (Jain Laboratory Instruments Pvt Ltd), Ambala, India

Sheet Metal Rolling Practicals

Students cut a blank from Galvanized Steel Sheet on the Guillotine Shears Machine and roll it into a cylinder for a pipe section or a small duct. They feed the sheet square to the rolls, raise the rear roll a little at a time and make several passes until the edges meet. The seam is then closed with a Rivet Gun.

Cones are rolled from a curved blank by feeding one end through faster than the other. The wire grooves in the rolls curve wire into rings, which can stiffen the rim of a rolled cylinder or tray.

Frequently Asked Questions

What is the smallest cylinder it can roll?
The minimum forming radius is 1-1/2 in, which is set by the 3 in diameter rolls. A tighter curve cannot be formed, because the sheet cannot wrap closer than the roll it bends around.

How thick a sheet can it roll?
Mild steel up to 16 gauge. Softer metals such as aluminium and copper roll more easily, while stainless steel should be kept to a lighter gauge than mild steel.

Should I choose the manual or the electric type?
Both share the same rolls, capacity and forming length. The manual type is turned by hand and suits small batches and teaching. The electric type drives the rolls at 22 RPM from a 3/4 hp three-phase motor and suits regular work on cylinders and duct.

Why do the ends of a rolled cylinder stay flat?
The first part of each edge cannot be bent, because it has not yet passed between all three rolls. Pre-bend both edges slightly before rolling, or trim the flats off after the cylinder is formed.

Why is it called a slip roll?
The name comes from the way a finished cylinder is slipped off the end of the upper roll once that roll is released. The cylinder does not have to be uncurled to get it out.

Other Sheet Metal Tools

For a quote, use Add To Cart or send us a message through the contact page.
